4.6
Optional Equipment
UVP offers a variety of optional equipment to support the needs of varying laboratory
environments. Refer to "Replacement Parts and Accessories" at the end of this manual for
optional equipment part numbers.
4.7
Thermal Printer
The thermal printer provides archive quality, 256 gray-
scale prints and five optional cost-effective print sizes.
4.8
UV Handheld Lamps for Epi (Overhead) Lighting
A set of two 4-watt ultraviolet lamps can be connected
inside the darkroom to provide epi UV illumination.
These lamps can be switched on or off using the switch
in front of the darkroom and can also be removed from
the darkroom and used as standalone handheld lamps
(as seen in the image to the right).
4.9
LED White Light Plate
The LED White Light Plate emits high uniformity with
less than 5 % coefficient of variance (CV). Plug the LED
White Light Plate directly into the power supply within
the system darkroom, or store it in the exterior dark-
room side pocket when not in use.
4.10
Converter Plates
An alternate to the LED White Light Plate, the
UV/White Converter Plate allows imaging of non-
fluorescent stained media with an ultraviolet transillumi-
nator. The converter plate is specially coated to convert
302 nm UV output to white light rather than using a
separate white light box or plate.
The Converter Plate Visi-Blue™ (not shown) converts
UV to a safe 460 – 470 nm wavelength designed for
use with blue excitation samples and SYBR Green,
SYPRO Orange and GFP stains.
81-0220-01 Rev R
System design
Thermal Printer
UV Lamp
LED White Light Plate
UV/White Converter Plate
11
