9

Maintenance, replacement parts/accessories

9.1

Care and cleaning

CAUTION! Risk of electrical shock!
Ensure that the system is turned OFF and unplugged during cleaning.


Transilluminator


9.2

Replacement parts and accessories

Replacement parts and accessories are listed below. Only authorized UVP service
personnel should perform repairs or replacements other than specified in these procedures.
For replacement parts of the transilluminator please refer the manual of the transilluminator.
For replacement parts or components not shown here, please call UVP Customer Service
or place of purchase. Please have the model number available when you call.
Part Description
Overhead (Epi) lighting:
UV Modules:
UV Compact Lamp, 254/365nm, 4 watt (115V)
UV Compact Lamp, 254/365nm, 4 watt (230V)
Fuses:
Fuse, 3.15A (for Darkroom)
Fuse, 2A (for Transilluminators)
Fuse, T1 Amp (for Motorized Lens Controller Box)
Emission Filters:
Filter, Ethidium Bromide, 50mm Square
Filter, SYBR Green, 50mm Square
81-0220-01 Rev R
Clean unit surface with a damp soft cloth or sponge. Use mild soap or detergent
solution.
Never use abrasive cleaners (can damage the UV filter surface of the transilluminator).
Do NOT use oil- or petroleum-based cleaners for the cabinet.
Clean the instrument only from outside.
The imaging system or the transilluminator must not be dipped into water or other
liquids!
To protect the filter glass and minimize moisture and liquids on the glass, it is
recommended that you use a UV transmitting Gel-Tray. Refer to the Replacement
Parts for ordering information.
When the transilluminator features a UV Blocking Cover only cleaning with a damp cloth
is allowed.
Alcohol and glass cleaner detergents attack the plastic and damage the UV protection
shield.
Maintenance, replacement parts/accessories
Part Number
95-0021-12 (2 Recommended)
95-0021-10 (2 Recommended)
56-0022-04 (2 Required)
56-0002-01 (2 Required)
56-0022-02 (2 Required)
38-0220-01
38-0219-01
