Installation Instructions
1
M5x12 screw
2
Top plate
3
Mounting backplate
4
Gasket between mounting backplate and exhaust duct spacer
Illustration 1.10 Installing the Duct Spacers
10
In-bottom/Out-back Cooling Kit for VLT®
Parallel Drive Modules
VLT® Series FC 102, FC 202, and FC 302
5
Duct spacer, exhaust
6
M5 nut
7
Gasket between exhaust duct spacer and back panel cover
8
Gasket between top plate and drive module
Danfoss A/S © 04/2016 All rights reserved.
MI92L102
