Installation Instructions
Tall Pedestal Kit for E1h/E2h Drives
®
VLT FC Series FC 102, FC 103, FC 202, and FC 302
Description
The tall pedestal kit contains all parts required to install the
tall pedestal for E1h and E2h drives. The tall pedestal is
400 mm (15.7 in) and replaces the standard pedestal that
ships with the drive.
Kit Ordering Numbers
Kit number Kit description
176F6764 Tall pedestal kit for E1h
176F6763 Tall pedestal kit for E2h
Table 1.1 Ordering Numbers for the Tall Pedestal Kit
Items Supplied
The tall pedestal kit contains the following items. Refer to
Illustration 1.1.
Item
Pedestal
Front panel
Front top bracket
Front bottom bracket
Locking brackets
M10x22 screw
M8 hex nut
M5x14 countersunk screw
M10 nylon-insert lock nut
Table 1.2 Items Supplied in Tall Pedestal Kit
Safety Information
Only qualified, Danfoss authorized personnel are allowed to
install the parts described in these installation instructions.
Handling of the drive and its parts must be done in
accordance with the corresponding operating guide.
ELECTRICAL SHOCK HAZARD
®
VLT
connected to mains voltage. Improper installation, and
installing or servicing with power connected, can cause
death, serious injury, or equipment failure.
To avoid death, serious injury, or equipment failure:
•
•
•
•
DISCHARGE TIME
Quantity
The drive contains DC-link capacitors, which can remain
1
charged even when the drive is not powered. High voltage
1
can be present even when the warning LED indicator lights
1 are off. Failure to wait 40 minutes after power has been
removed before performing service or repair work can result
1
in death or serious injury.
2
6
•
4
•
6
2
•
•
•
Danfoss A/S © 03/2018 All rights reserved.
WARNING
FC series drives contain dangerous voltages when
Only use qualified electricians for the installation.
Disconnect the drive from all power sources before
installation or service.
Treat the drive as live whenever the mains voltage
is connected.
Follow the guidelines in these instructions and local
electrical safety codes.
WARNING
Stop the motor.
Disconnect AC mains and remote DC-link power
supplies, including battery back-ups, UPS, and DC-
link connections to other drives.
Disconnect or lock PM motor.
Wait 40 minutes for capacitors to discharge fully.
Before performing any service or repair work, use
an appropriate voltage measuring device to make
sure that the capacitors are fully discharged.
