Installation Instructions
Bus Bar Kit for 12-pulse, 2-drive System
®
VLT Series FC 102, FC 202, and FC 302
Description
The bus bar kit is designed for the specific VLT
®
102, VLT AQUA Drive FC 202, and VLT
®
302 D4h-size VLT Parallel Drive Modules mounted in a Rittal
TS8 enclosure. The bus bars in this kit link 2 drive modules in
parallel.
Kit Part Number
Part number Kit description
176F6489
Bus bar kit for the VLT
(12-pulse, 2-drive system)
Table 1.1 Part Number for the VLT
Bus Bar Kit
Items Supplied
The kit contains the following parts:
Bus bar assembly
•
Nut with integrated washer, M5 (10)
•
Nut with integrated washer, M8 (10)
•
Nut with integrated washer, M10 (6)
•
Screw, M5 x 12 mm (40)
•
Screw with integrated washer, M10 x 30 (6)
•
Stand-off, M5 x 25 (15)
•
Ground bus bar, 800 mm (1)
•
Ground plate (1)
•
Ground jumper plate (2)
•
Ground jumper bus bar (2)
•
Ground clamp (1)
•
EMI/EMC bracket, left (2)
•
EMI/EMC bracket, right (2)
•
EMI/EMC bracket, front (2)
•
EMI/EMC shield, lower (1)
®
HVAC Drive FC
®
AutomationDrive FC
®
Parallel Drive Modules
®
Parallel Drive Modules
Danfoss A/S © 04/2016 All rights reserved.
DC bus assembly
•
L-brackets (2)
•
DC-link jumper bus bar (-) (2)
•
Jumper bus bar (+) (2)
•
DC bus support plate (1)
•
DC-link bus bar (2)
AC bus bar assembly
•
Brake terminal, left (2)
•
Brake terminal, right (2)
•
Brake terminal bracket (2)
•
Solid AC bus bar, (6)
•
AC bus bar assembly bracket (1)
•
S-bracket (1)
•
Flexible AC bus bars (6)
•
AC support bracket (1)
•
Side support (2)
Safety
WARNING
DISCHARGE TIME
The frequency converter contains DC-link capacitors, which
can remain charged even when the unit is off. High voltage
can be present even when the warning indicator lights are
off. Failure to wait 20 minutes after power has been
removed before performing service or repair work, could
result in death or serious injury.
•
Stop the motor.
•
Disconnect the AC mains, permanent magnet type
motors, and remote DC-link supplies, including
battery back-ups, UPS, and DC-link connections to
other frequency converters.
•
Wait 20 minutes for the capacitors to discharge fully,
before performing any service or repair work.
•
Measure the voltage level to verify full discharge.
Installation
If both a bus bar kit and a back-channel cooling kit are
being installed in the cabinet, install the back-channel
cooling kit first.
