Installation Instructions
In-back/Out-top Cooling Kit for VLT
Parallel Drive Modules
®
VLT
Series FC 102, FC 202, and FC 302
Description
The in-back/out-top cooling kit is designed for the specific
®
VLT
HVAC Drive FC 102, VLT
AutomationDrive FC 302 D4h-size VLT
mounted in a Rittal TS8 enclosure. The kit directs air in from
the back of unit and out through the top of the unit. See
Illustration 1.1.
1
Back-channel airflow (exhaust)
2
Base duct assembly
3
Mounting backplate
4
Back-channel airflow (intake)
Illustration 1.1 Direction of Airflow with the Kit Installed
Kit Part Number
Part number
Kit description
176F6494
In-back/Out-top Cooling Kit for the VLT
Drive Modules (2-drive system)
Table 1.1 Part Number for the VLT
In-back/Out-top Cooling Kit
®
AQUA Drive FC 202, and VLT
®
Parallel Drive Modules
®
Parallel
®
Parallel Drive Modules
Danfoss A/S © 04/2016 All rights reserved.
Items Supplied
Upper duct assembly
®
1
Gasket between grill and cabinet (1)
2
Grill (1)
3
Gasket, top front cover (1)
4
Gasket, left front cover (1)
5
Gasket, bottom front cover (1)
6
Front cover plate (1)
7
Gasket between duct enclosure and grill (1)
8
Duct enclosure (1)
9
Gasket, right front cover (1)
10
Gasket between duct enclosure and base plate (1)
11
Base plate (1)
12
Gasket between base plate and module (1)
–
Nuts, M5 (26)
–
Screws, M5x12 (6)
Illustration 1.2 Upper Duct Assembly for 1 Drive Module
®
MI92K102
