Introduction

Complete system control
The Xanbus SCP provides configuration and monitoring capability for a
Xanbus system. The SCP:
• Monitors activity throughout your power system.
• Displays the settings and status of each Xanbus-enabled device.
• Enables you to adjust settings for each Xanbus-enabled device.
System component The Xanbus SCP is part of a network
communications protocol developed by Xantrex, to communicate its
settings and activity to other Xanbus-enabled devices.
Xanbus-enabled products are:
• Easy to use. The Xanbus network simplifies operation and automates
routine tasks.
• Reliable. Software control eliminates errors due to analog signaling.
• Accurate. Digital information is less susceptible to interference and
line loss.
• Upgradable. Software upgrades mean your purchase will remain up to
date.
97-0022-01-01
IMPORTANT: The Xanbus SCP is compatible with Xanbus-enabled devices
such as Freedom SW 2012/2024 (PN: 815-2012/815-2024) and
Freedom SW 3012/3024 (PN: 815-3012/815-3024 ) inverter/chargers as
well as the Xanbus Automatic Generator Start (PN: 809-0915).
The SCP is not compatible with Prosine, Freedom SW 2000, Freedom SW
3000, Freedom HW, and Freedom HF, or RV Series inverter/chargers from
Xantrex.
System requirements
The SCP requires a Xanbus power supply to operate. Network power is
carried by the network cables, and can be supplied by a Xanbus-enabled
product (such as an inverter/charger) or an external Xanbus power supply.
As a device that draws network power, the SCP consumes a maximum of 3
watts.
For detailed instructions and a complete list of Xanbus-enabled devices,
visit the website at www.xantrex.com.
1
