Specifications

NOTE: Specifications are subject to change without prior notice.
Electrical Specifications
Nominal input network 12 Vdc
voltage
Maximum operating current
200 mA @ nominal input network voltage
Communication physical layer 2, CAN
Communication protocol
Xanbus
Maximum cable length
40 m (130 ft)
Connectors 2 RJ-45—8 pins
Display
Dot matrix 128 × 64 LCD with white LED backlight
Physical Specifications
Dimensions (W × H × D)
152 × 103 × 40 mm (6 × 4 × 1
Shipping dimensions
267 × 210 × 63 mm (10½ × 8 ¼ × 2 ½")
Weight
208 g (0.46 lb)
Shipping weight
780 g (1.72 lb)
Environmental Specifications
Operating temperature
Storage temperature
34
9
----- - ")
16
-20 to 50 °C (-4 to 122 °F)
-40 to 85 °C (-40 to 185 °F)
Environmental Specifications
Maximum case temperature
Operating humidity
Storage humidity
Regulatory Approvals
Safety
EMC
Xanbus System Control Panel (SCP) Owner's Guide
60 °C (140 °F)
5% to 95%
5% to 95%
CSA certified to CSA 107.1-01 and UL 458 4th
Ed. including the marine supplement
FCC Part 15, Class B
Industry Canada ICES-0003 Class B
