Xanbus-Enabled Device Configuration Using the SCP

The SCP can display and change the settings for any Xanbus-enabled
device in the Xanbus system.
97-0022-01-01
Using SCP Buttons
The SCP has four buttons for moving between status screens and menus,
highlighting settings you want to change, selecting and changing
configurable values for Xanbus-enabled devices.
Button Function
Enter
• Confirms selection of a menu item.
• Moves you to the next screen.
Down Up • Scrolls down (up) one line of text.
and
arrow • Decreases (increases) a selected value.
When the Func button is pressed to select:
buttons:
• "Shr" - the down (and up) arrow buttons increment
(decrement) shore power breaker capacity on a
Freedom SW inverter/charger
• "AGS" - the down (and up) arrow buttons switch
between different AGS Start modes (Auto, Manual-
On, Manual-Off).
• "Home" - the down (and up) arrow buttons enable or
disable the inverter.
Func
• Cancels selection of a menu item.
• Returns you to the previous screen.
• Changes the functions of the Up and Down arrow
buttons
a. If the Freedom Sequence power manager is installed in the power system, the shore breaker capacity on
the power manager is adjusted but not the inverter/charger.
a
.
