Xantrex Xanbus System Control Panel Owner's Manual page 26

Xanbus-Enabled Device Configuration Using the SCP
Configuring the Xanbus System Control
Panel (SCP)
You can configure the SCP to suit your preferences and the requirements of
the Xanbus system. Some settings, such as the system time, affect the entire
system. Other settings affect only the SCP, such as the brightness of the
display.
You can perform all these tasks on the SCP Setup menu, the Clock menu,
and the System Settings menu.
Configuring the SCP is done on the SCP Setup menu, which you can view
in either basic or advanced formats.
To view the SCP Setup menu:
From the System Status screen, press Enter to view the
1.
Select Device menu.
On the Select Device menu, highlight XSCP and press Enter.
2.
Select Device
FSW3012 00
FSW3012 01
XSCP
Clock
18
SCP Configuration Items
The SCP Setup menu contains settings for changing the appearance of the
display, enabling button-press and alarm sounds, and setting the
temperature scale. Items in gray appear only on the advanced menu.
Menu item Description
Brightness Adjusts the brightness of the
display to suit interior light
conditions and enhance visibility.
Contrast Adjusts the contrast of the display
to suit viewing angle and enhance
visibility.
Sets how long the backlight
Light Timer
remains on after the last button
press on the SCP.
Enables buttons to beep when
Button Beep
pressed.
Enables an alarm to sound when a
Fault Alarm
fault occurs.
LoBatt Alarm Enables an alarm to sound when a
low battery voltage condition
exists.
Set Degrees Selects the temperature scale the
SCP will display.
Name Allows you to customize the name
of the SCP as it is displayed on the
setup menu and the Select
Device menu.
Xanbus System Control Panel (SCP) Owner's Guide
Values/Action Default
20% to 100% 60%
(increments of 10%)
0% to 100% 60%
(increments of 5%)
Off, 1mins–60mins 2mins
(increments of 1 minute)
On, Off Off
On, Off Off
On, Off Off
Fahrenheit, Celsius Fahrenheit
Press Enter to begin
SCP
customizing the name.
See "Setting the Device
Name" on page 20.
