System Status Screen
The System Status screen appears after the Startup screen. The System
Status screen displays aggregated status information for the entire
1
power system .
The System Status screen always features a menu arrow pointing to the
Enter button. Pressing Enter displays the Select Device menu.
IMPORTANT: If you are uncertain which Xanbus System Control Panel
(SCP) screen or menu you are viewing, you can always return to the
starting point—the System Status screen—by pressing Func until the
System Status screen appears.
Select Device Menu
The Select Device menu displays a list of Xanbus-enabled devices in
the system, including the Accessories and the Xanbus System Control
Panel (SCP). The Select Device menu is where you can access the Setup
menus for each device in the system. The length of the Select Device
menu depends on how many Xanbus-enabled devices are installed.
The Select Device menu also contains the Clock menu (where the time
and date are set) and the System Settings menu (where system-level
settings can be configured). The System Settings, XSCP, and Clock
menus are always available from the Select Device menu, regardless of
the number of Xanbus-enabled devices installed.
1.As an example, a power system can have five Xanbus network-connected devices – up to
a maximum of two Freedom SW Inverter/Chargers, one Freedom Sequence power manager, one
Xanbus AGS module, and one Xanbus SCP all connected to a single battery bank, a single generator
and a common utility grid.
97-0022-01-01
Xanbus-Enabled Device Configuration Using the SCP
To display the Select Device menu:
◆
From the System Status screen, press Enter.
Device Setup Menus
Device Setup menus display status information and changeable settings.
Changeable settings are identified by the square brackets [ ] around values
in the right-hand column.
To display the Setup menu for a device:
◆
On the Select Device menu, highlight the device name and press
Enter.
Select Device menu
Select Device
System Settings
FSW3012 00
XSCP
To view Device Setup
Clock
menu, highlight the device
name and press Enter
Complete Device
Setup menu list.
NOTE: The Xanbus System Control
Panel (SCP) displays only four lines
of the Setup menu at one time. To
view additional settings, press the
Down arrow button.
Figure 9 Selecting a Device Setup Menu
FSW Inverter/Charger
Setup menu
FSW3012 00: Setup
Inverter [Enabled]
Search Mode [Disabled]
Charger [Enabled]
Force Chg
FSW3012 00: Setup
Inverter [Enabled]
Search Mode [Disabled]
Charger [Enabled]
Force Chg
Equalize [Disabled]
[Operating]
Mode
Clear Faults/Warnings
View Device Info
Basic Settings
