YASKAWA AC Drive L1000A
AC Drive for Elevator Applications
Quick Start Guide
Type: CIMR-LC A
Models: 200 V Class: 4.0 to 45 kW
400 V Class: 4.0 to 75 kW
To properly use the product, read this manual thoroughly and retain
for easy reference, inspection, and maintenance. Ensure the end user
receives this manual.
MANUAL NO. TOEP C710616 33A
PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor
Advertisement
Table of Contents
Related Manuals for YASKAWA CIMR-LC2A0018
Summary of Contents for YASKAWA CIMR-LC2A0018
- Page 1 YASKAWA AC Drive L1000A AC Drive for Elevator Applications Quick Start Guide Type: CIMR-LC A Models: 200 V Class: 4.0 to 45 kW 400 V Class: 4.0 to 75 kW To properly use the product, read this manual thoroughly and retain for easy reference, inspection, and maintenance.
- Page 2 Yaskawa. No patent liability is assumed with respect to the use of the information contained herein. Moreover, because Yaskawa is constantly striving to improve its high-quality products, the information contained in this manual is subject to change without notice. Every precaution has been taken in the preparation of this manual.
-
Page 3: Table Of Contents
9 SAFE DISABLE INPUT FUNCTION ........41 YASKAWA ELECTRIC TOEP C710616 33A YASKAWA AC Drive L1000A Quick Start Guide... -
Page 4: Safety Instructions And General Warnings
Any warnings provided by Yaskawa must be promptly provided to the end user. Yaskawa offers an express warranty only as to the quality of its products in conforming to standards and specifications published in the manual. - Page 5 Failure to comply could result in death or serious injury. Yaskawa is not responsible for any modification of the product made by the user. This product must not be modified. Do not touch any terminals before the capacitors have fully discharged.
- Page 6 Carefully review the braking option instruction manual when connecting a braking option to the drive. YASKAWA ELECTRIC TOEP C710616 33A YASKAWA AC Drive L1000A Quick Start Guide PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor...
- Page 7 Failure to comply could result in damage to the drive and will void warranty. Yaskawa is not responsible for modification of the product made by the user. This product must not be modified. Check all the wiring to ensure that all connections are correct after installing the drive and connecting other devices.
-
Page 8: Mechanical Installation
The degree of protection of L1000A drives is IP20. Install the drive in a cabinet if higher degree of protection is required. YASKAWA ELECTRIC TOEP C710616 33A YASKAWA AC Drive L1000A Quick Start Guide PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor... - Page 9 – 4A0031 – – – 4A0039 – – – 4A0045 4A0060 4A0075 4A0091 4A0112 4A0150 YASKAWA ELECTRIC TOEP C710616 33A YASKAWA AC Drive L1000A Quick Start Guide PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor...
-
Page 10: Electrical Installation
Programming Mode. Use the “Drive Ready” output (default set to terminals M5-M6) to interlock operation in such situations. YASKAWA ELECTRIC TOEP C710616 33A YASKAWA AC Drive L1000A Quick Start Guide PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor... -
Page 11: Model
Control Circuit The control terminal board is equipped with screwless terminals. Always use wires within the specifications listed below. For safe wiring, Yaskawa recommends solid wires or flexible stranded wires with ferrules. Use ferrules with a length of 8 mm. - Page 12 • when using an advancing capacitor switch. • with a large capacity power supply transformer (over 600 kVA). YASKAWA ELECTRIC TOEP C710616 33A YASKAWA AC Drive L1000A Quick Start Guide PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor...
-
Page 13: Model
(+1, −) connection (+3, −) • a DC reactor Not available – Grounding terminal YASKAWA ELECTRIC TOEP C710616 33A YASKAWA AC Drive L1000A Quick Start Guide PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor... - Page 14 External Power Supply – Sourcing Mode (PNP) Internal Power Supply – Sourcing Mode (PNP) 24 Vdc 24 Vdc External 24 Vdc YASKAWA ELECTRIC TOEP C710616 33A YASKAWA AC Drive L1000A Quick Start Guide PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor...
- Page 15 Ensure the diode rating is greater than the circuit voltage. Flywheel diode DC Power Reactive I (max 50 mA) Supply (max 48 V) load YASKAWA ELECTRIC TOEP C710616 33A YASKAWA AC Drive L1000A Quick Start Guide PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor...
-
Page 16: Keypad Operation
• When an alarm occurs. • When oPE is detected. • When a fault or error occurs during Auto-Tuning. YASKAWA ELECTRIC TOEP C710616 33A YASKAWA AC Drive L1000A Quick Start Guide PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor... - Page 17 <4> The speed reference appears after the initial display which shows the product name. <5> The information that appears on the display will vary depending on the drive. YASKAWA ELECTRIC TOEP C710616 33A YASKAWA AC Drive L1000A Quick Start Guide PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor...
-
Page 18: Start Up
• Adjust settings for the brake sequence. • Adjust speed control loop (C5- ) etc. FINISH YASKAWA ELECTRIC TOEP C710616 33A YASKAWA AC Drive L1000A Quick Start Guide PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor... -
Page 19: Troubleshooting
Note: Always set the motor rotation direction prior to the encoder rotation direction. Refer to Motor Rotation Direction Setup on page YASKAWA ELECTRIC TOEP C710616 33A YASKAWA AC Drive L1000A Quick Start Guide PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor... - Page 20 • Input motor data like on name plate. Make sure to convert data into the correct unit before. The drive automatically calculates the motor data. YASKAWA ELECTRIC TOEP C710616 33A YASKAWA AC Drive L1000A Quick Start Guide PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor...
- Page 21 “END” will appear on the operator panel. Do not touch the motor until this display is shown and the motor has completely stopped. YASKAWA ELECTRIC TOEP C710616 33A YASKAWA AC Drive L1000A Quick Start Guide PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor...
- Page 22 Open terminals H1-HC and H2-HC if used during the normal sequence. Open the Baseblock input (H1- =8/9) if used. FINISH YASKAWA ELECTRIC TOEP C710616 33A YASKAWA AC Drive L1000A Quick Start Guide PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor...
- Page 23 Open terminals H1-HC and H2-HC if used during the normal sequence. Open the Baseblock input (H1- =8/9) if used. FINISH YASKAWA ELECTRIC TOEP C710616 33A YASKAWA AC Drive L1000A Quick Start Guide PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor...
- Page 24 Open terminals H1-HC and H2-HC if used during the normal sequence. Remount the ropes if removed during tuning. FINISH YASKAWA ELECTRIC TOEP C710616 33A YASKAWA AC Drive L1000A Quick Start Guide PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor...
- Page 25 Multi speed inputs 2, Speed references are set in d1-02 to d1-08, Stop if no speed selection input is enabled YASKAWA ELECTRIC TOEP C710616 33A YASKAWA AC Drive L1000A Quick Start Guide PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor...
- Page 26 Set Value Details H1-03 Nominal speed (d1-19) H1-05 Intermediate speed 1 (d1-20) H1-06 Leveling speed (d1-26) YASKAWA ELECTRIC TOEP C710616 33A YASKAWA AC Drive L1000A Quick Start Guide PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor...
- Page 27 Speed Safe disable Up/Down Leveling speed Leveling speed has priority Selected speed YASKAWA ELECTRIC TOEP C710616 33A YASKAWA AC Drive L1000A Quick Start Guide PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor...
- Page 28 Set in units of m/s as the accel/decel change rate. setting of C1- and vice versa. YASKAWA ELECTRIC TOEP C710616 33A YASKAWA AC Drive L1000A Quick Start Guide PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor...
- Page 29 • If C1-15 > 0, the drive decelerates to stop, closes the brake, shuts the output off and opens the motor contactor. YASKAWA ELECTRIC TOEP C710616 33A YASKAWA AC Drive L1000A Quick Start Guide PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor...
