To Define a Math
Waveform
Overview
To define a math waveform
Prerequisites
1.
All channel and reference Waveforms and automatic
measurement scalars that you will use in your math
waveform must be available (channels and references
contain data, measurement scalars are defined, and so
on).
Display the
2.
From the toolbar, touch the Math button to display the
Define Math control window.
math control
window
Select a math
3.
Select the Math(x) tab for the math waveform that you
want to define. Be sure to touch Display to toggle it on,
waveform
so that the waveform displays.
If the waveform that you select already exists, its math
expression appears in the window. You can still use the
waveform by touching the Clear button, which discards
its previous math expression. Or repeat step 3 to select
another waveform.
To define an
4.
Touch one of the Predefined Expression buttons to use
a predefined math expression, or touch Editor to
expression
Define/Edit a new math expression.
CSA7000B Series & TDS7000B Series Instruments User Manual
Use the procedure that follows when defining a math waveform. Remember, to
ensure that the sources you use exist. Acquisitions should be running or the
channels should already be on, and reference waveform sources should contain
saved waveforms, and so on. These sources do not have to be displayed to be
used.
Creating and Using Math Waveforms
Related control elements and resources
See page page 3- - 29 for acquisition setup and page 3- - 63
for trigger setup.
3- 175
