Data Input/Output
Overview To use exported waveforms (Cont.)
For further 9. For more help on exporting waveforms, touch the
Help button in the window to access contextual online
assistance
help.

To Copy Your Waveform

Overview To save a waveform
Prerequisites 1. Make sure the waveform, image, or measurement to be
copied exists; that is, your source must be a channel, an
active math waveform, an active reference, and so forth.
Select for copy 2. From the menu bar, select Edit, and then select Select
for Copy.
The menu lists all available waveform, image, and
measurement types available for export:
H
H
H
H
Select setup for 3. From the menu bar, select Edit, and then select Copy
copy Setup to display the Copy Setup control window.
3- 246
Use the procedure that follows to copy a waveform to the clipboard.
Full Screen to export a bitmap of all screen
contents
Graticule to export a bitmap of only the graticule
area
Waveform to export waveform data
Measurements to export measurement data
CSA7000B Series & TDS7000B Series Instruments User Manual
Control elements and resources
See page 3- - 263 to learn about accessing online help.
Control elements and resources
H
See Powering On the Instrument on page 1- - 9.
H
See page 3- - 29 for acquisition setup.
H
See page 3- - 63 for trigger setup.
