Data Input/Output
Overview To clear references (Cont.)
Delete a 4. To display the Delete Reference Waveform window,
reference from the Delete Wfm File window, touch Delete.
waveform file
The Delete Reference Waveform window allows
navigation to directories, lists waveform files in the
directory, and provides for selection of a waveform file.
Find the file 5. Use the Look in: drop-down list and buttons to navigate
directory to the directory of the file to delete.
Find your file 6. Select the file type in the Files of type drop-down list to
force the file listing to only include these types. Use
*.wfm for waveforms.
Note. Only change the type if you want to temporarily
see any other types of files in the current directory.
Otherwise, leave it set to *.wfm for waveforms.
7. Choose your waveform file by clicking an existing name
in the file list.
Note. If your instrument lacks a keyboard, touch or click
the keyboard icon to display a virtual keyboard. You can
use the mouse or touch screen with the virtual keyboard
to type entries in the name fields.
3- 234
Control elements and resources
CSA7000B Series & TDS7000B Series Instruments User Manual
Access to virtual keyboard
