9.0

Replacement of the batteries

Please proceed as follows when you need to change the batteries:
•
Remove the belt clip carefully (if you use a small Phillips screwdriver, you do not
need to remove the belt clip).
•
Remove the screw on the back of the unit.
•
Detach the bottom half of the housing.
•
Take out the old batteries and insert the new batteries with the positive pole
pointing upwards as shown in the diagram. Observe correct polarity and make
sure you are using the correct battery type.
•
Replace the bottom half of the housing and fasten the screw finger-tight.
•
Attach the belt clip.
SmartCD Programming Device
+
-
+
Batteries
-
Antenna
8
