SmartCD Programming Device
Page 7
8.0
Antenna orientation
The antenna orientation for selected components is shown below to guarantee
faultless programming. To ensure the largest possible range when programming, the
antennas of the SmartCD and the lock should be aligned parallel to one another.
To prevent over-modulation, however, the distance between the antennas should
always be at least 10 cm.
SmartCD
Cylinder
Smart Relay
Antenna
All antennas are aligned parallel to one another in this example.
7
