MAINTENANCE:

1. Motor: Inspect the motor once a year - motor should rotate freely.
2. Wheel: Inspect the venter wheel annually to clear any soot, ash or coating which inhibits either rotation
or air fl ow. Remove all foreign materials before operating.
3. Vent System: Inspect all vent connections annually for looseness, for evidence of corrosion, and for fl ue
gas leakage. Replace, seal, or tighten pipe connections if necessary. Check the power venter choke plate
to ensure it is secured in place. Check the barometric draft control, if installed, to ensure the gate swings
freely.
4. System Safety Devices: With the heating system operating, disconnect the pressure sensing tube from
the pressure switch on the CK Kit. This should stop the burner operation. Reconnecting the tube will
relight the burner. For 30 millivolt operating systems, disconnect one lead of the spill switch circuit from
the thermocouple junction block. This should shut off the pilot and the burner. Re-connection will allow
relighting the pilot.
REPLACEMENT PARTS
The following items are available for replacement, if necessary.

REPLACEMENT PARTS LIST

Part Number
46032000
46032000
46083300
46226500
46080100
46033400
46089400
46124000
page 10
Description
PVE-100 Motor
PVE-300 Motor
PVE-600 Motor
PVE-1200 Motor
PVE-100 Blower Wheel
PVE-300 Blower Wheel
PVE-600 Blower Wheel
PVE-1200 Blower Wheel
