Field Controls PVO-600 Instruction Manual

Power venter system
Hide thumbs Also See for PVO-600:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Manual
Included is one ETL and cETL listed Power Venter to be used primarily with a
single 120VAC controlled oil fired furnace, boiler, or water heater. The PVO
may be used to common vent multiple appliances with the addition of a Control
Kit. Please consult Field Control's Technical Support for other options.
TYPICAL VENTING SYSTEM COMPONENTS
One PVO Series Power Venter with pre-wired controls; adjustable post
purge relay timer, adjustable draft proving switch, direct access terminal
blocks, and piping tee for multiple appliance systems.
• Side Wall Vent Hood (Not included)
• CK-Series Control Kit for multiple appliance venting (Not Included)
This device MUST be installed by a qualified agency in accordance with the manufacturers installation
instructions.
The definition of a qualified agency is: any individual, firm, corporation or company which either in person or through a representative is
engaged in, and is responsible for, the installation and operation of gas appliances, who is experienced in such work, familiar with all
the precautions required, and has complied with the requirements of the authority having jurisdiction.
POWER VENTER SYSTEM
Model: PVO-300, PVO-600
C
ONTENTS
DO NOT DESTROY
THESE INSTRUCTIONS MUST REMAIN WITH EQUIPMENT
2630 Airport Road · Kinston, NC 28504
Phone: 252-522-3031· Fax: 252-522-0214
• Spill Switches (Not included)
www.fieldcontrols.com
P
AGE
2
2
3
4
5
5-6
7
7
7
7
8
8
9
10
10

Advertisement

Table of Contents
loading

Related Manuals for Field Controls PVO-600

Summary of Contents for Field Controls PVO-600

  • Page 1: Table Of Contents

    THESE INSTRUCTIONS MUST REMAIN WITH EQUIPMENT Model: PVO-300, PVO-600 • Spill Switches (Not included) DO NOT DESTROY 2630 Airport Road ·...

  • Page 2: Unit Specifications

    UNIT SPECIFICATIONS (See Table 1 and Figure 1) Table 1 UNIT DIMENSIONS (INCHES) MODEL “H” “W” PVO-300 7.50 9.25 PVO-600 8.75 9.75 Inlet and outlet diameter. ELECTRICAL RATINGS MODEL PVO-300 3000 PVO-600 3000 Thermally protected motor. SIDEWALL VENT HOODS (Model SWH-1) Sidewall vent hoods are available in the following sizes.

  • Page 3: Power Venter Sizing

    Total Equivalent Feet = 14 Ft. + 20 Ft. = 34 Ft. VENTER MODEL NO. AND VENT PIPE DIAMETER PVO-300 4” 5” 6” QUIVALENT ENGTH VENT PIPE DIAMETER 3” 4” 5” 6” Page 3 PVO-600 5” 6“ 8” 7” 8” 9” 10” Figure 3...

  • Page 4: Installation Safety Instructions

    Use a Field Controls Type MG-1 Barometric Draft Control. Gas-fired draft induced systems should have a single-acting or double-acting barometric draft control installed.

  • Page 5: Installation Of Power Venter

    INSTALLATION OF POWER VENTER CAUTION: Failure to install, maintain and/or operate the power venting system in accordance with manufacturer's instructions will result in conditions which may produce bodily injury and/or property damage. 1. Remove power venter from box and inspect unit for damage. If the carton has been crushed or mutilated, check unit very carefully for damage.
  • Page 6 Diagram B Diagram C Page 6...

  • Page 7: Airflow Adjustments

    ULTIPLE PPLIANCE YSTEMS When using one PVO power venter to common vent more than one appliance, a Control Kit is required for each additional appliance. 1. Connect the negative pressure port of each air pressure fan proving switch on all Control Kits being used to the provided tee mounted on the PVO.

  • Page 8: General Installation Inspection

    MAINTENANCE 1. Motor: Inspect the motor once a year - motor should rotate freely. To prolong the life of the PVO-600 motor, it must be lubricated with six drops of SWG Superlube, Part #46226200, annually. The PVO-300 has sealed ball bearings, and therefore does not need to be oiled.
  • Page 9 PV SERIES POWER VENTER: VERTICAL VENTING OPTION Diagram D illustrates correct and incorrect installation of PV series venter in vertical vent configuration (except PVE- 1200). The correct installation maintains the required vertical position of the pressure switch; the incorrect installation does not.

  • Page 10: Replacement Parts List

    MODEL NO.:____________________________________________________________ INSTALLER'S NAME:_____________________________________________________ INSTALLER'S COMPANY: _________________________________________________ INSTALLER'S PHONE NO.: ________________________________________________ DATE OF INSTALLATION:_________________________________________________ REPLACEMENT PARTS LIST DESCRIPTION PVO-300 Motor 46032000 Blower Wheel 46033400 Post Purge Relay Timer 46144700 Pressure Switch 46311000 Date: PVO- Page 10 PVO-600 46083300 46089400 4614470 46311000...
  • Page 11 NOTES Page 11...
  • Page 12 Page 12 P/N 46311800 Rev E 11/07...
