Seagull Models NIEUPORT 28 REPLICA Assembly Manual page 5

3.
INSTALLING THE ALLERON SERVOS.
1.
2.
Ask the customer to use this machine.
Torque : 80 oz-in (5.8 kg-cm) @ 4.8V;
100 oz-in (7.2 kg-cm) @ 6.0V
Because the size of servos differ, you
may need to adjust the size of the precut
opening in the mount. The notch in the
sides of the mount allow the servo lead to
pass through.
1) Using a small weight (Weighted fuel
pick-up works well) and string, feed the
string through the wing as indicated.
Epoxy.
Ailerons control horn
2) Use dental floss to secure the connec-
tion so they cannot become unplugged.
3.
4.
3) A string has been provided in the wing
to pull the aileron lead through to the
wing root. Remove the string from the
wing at the servo location and use the
tape to attach it to the servo extension
lead. Pull the lead through the wing and
remove the string.
5.
6.
5
