Seagull Models NIEUPORT 28 REPLICA Assembly Manual page 16

NIEUPORT 28 REPLICA
Then, use 5.5mm drill bit to enlarge the
holes on the electric motor box.
6.
7.
5) Attach the motor to the front of the
electric motor box using four 4mm blind
nut, four M4x20mm hex head bolts to se-
cure the motor. Please see picture shown.
8.
M4x20mm
16
5.5mm
Blind nut.
Instruction Manual.
9.
10.
11.
Epoxy.
6) Attach the speed control to the side of
the motor box using two-sided tape and
tie wraps. Connect the appropriate leads
from the speed control to the motor. Make
sure the leads will not interfere with the
operation of the motor.
12.
145mm
Balsa stick.
Speed cotrol.
