2842i_Manuals 4/27/18 2:08 PM Page 6

5. Using the Product

Note: It is important to verify the calibration of the instrument. Please

refer to the calibration section for further information.

Power On the Level

Tap

to power on the level. The unit will display a reading on both

the main display and top-read display. The level indicator arrows

on each side of both LCD displays indicate the direction that side

of the level must be moved to reach level.

If you invert the level, both the main display and top-read display will

automatically flip.

Note: If the level is tilted 30° or more, the main display and top-read

display will read "out," indicating the sensor is out of its accuracy

range.

Automatic Shut Off / Manually Power Off the Level

To conserve battery life, this level features an automatic shut off fea-

ture. After 10 minutes of inactivity, the level will beep twice and

automatically shut off.

To manually power off the level, press and hold

and turn off.

. It will beep twice
