Magnetic Torpedo Laser Level
Model No. 40-0915
Instruction Manual
Congratulations on your choice of this Magnetic Torpedo Laser Level.
We suggest you read this instruction manual thoroughly before using
the instrument. Save this instruction manual for future use.
This is a Class IIIa laser tool and is manufactured to comply
with CFR 21, parts 1040.10 and 1040.11 as well as international
safety rule IEC 285.
©2007 Johnson Level & Tool
1
Advertisement
Table of Contents
Related Manuals for Johnson Level & Tool 40-0915
Summary of Contents for Johnson Level & Tool 40-0915
- Page 1 Save this instruction manual for future use. This is a Class IIIa laser tool and is manufactured to comply with CFR 21, parts 1040.10 and 1040.11 as well as international safety rule IEC 285. ©2007 Johnson Level & Tool...
-
Page 2: Table Of Contents
• Magnetic bottom allows unit to be attached to metal 3. Safety Instructions Please read and understand all of the following instructions, prior to using this tool. Failure to do so, may void the warranty. ©2007 Johnson Level & Tool... - Page 3 • Remove the batteries when storing the tool for an extended time (more than 3 months) to avoid damage to the tool should the batteries deteriorate. • Do not attempt to repair or disassemble the laser tool. If unqualified persons attempt to repair this tool, warranty will be void. ©2007 Johnson Level & Tool...
-
Page 4: Location/Content
WARNING! The tinted goggles are designed to enhance the visibility of the laser beam. They DO NOT offer protection to the eyes from direct exposure of the laser beam. 4. Location/Content of Warning Labels ©2007 Johnson Level & Tool... -
Page 5: Location Of Parts/Components
5. Location of Part/Components Vertical Power Switch Bubble Cross Check Vial Rotating/Head Pivot Rear Leveling Horizontal Bubble Foot Adjustment Battery Compartment Rear Foot Front Foot Magnet ©2007 Johnson Level & Tool... -
Page 6: Using The Product
Rotating the conversion head lens counter-clockwise, while in line mode, rotates line from horizontal to vertical. Rotate to switch between point and line ©2007 Johnson Level & Tool... -
Page 7: Technical Specifications
2 “AAA” alkaline batteries Battery Life Approx. battery life 70 hours continuous use Dimensions 2" x 7" x 7/8" (51 x 177 x 22mm) Weight 0.3 lbs. (0.14 Kg) Working Temperature 14°F to 113°F (-10°C to +45°C) ©2007 Johnson Level & Tool... -
Page 8: Application Demonstrations
8. Application Demonstrations Projects one laser point Projects one horizontal laser line Projects one vertical laser line ©2007 Johnson Level & Tool... -
Page 9: Care And Handling
Keep the laser unit dry and clean, especially the laser output • window. Remove any moisture or dirt with a soft, dry cloth. Do not use harsh chemicals, strong detergents or cleaning solvents • to clean the laser unit. ©2007 Johnson Level & Tool... -
Page 10: Product Warranty
10. Product Warranty Johnson Level & Tool offers a one year limited warranty on each its products. You can obtain a copy of the limited warranty for a Johnson Level & Tool product by contacting Johnson Level & Tool's Customer Service Department as provided below or by visiting us online at www.johnsonlevel.com.
