7. Application Demonstrations

ADA Compliant Ramps – Set ramp angles and

cross angles.

Drainage Slope – Set drainage angles for proper

slope to ensure adequate effluent removal from

your piping systems.

Relative Angles – Calculate relative angles using

the hold feature. Join conduit, piping and more at

any desired angle.

Roof Pitch – Measure the slope of any surface,

including roof pitches, directly in 12ths.

General Carpentry – While this level is generally

used in slope applications, its level vials make it

suitable for use anywhere a standard level is used.
