2. Tap a second time to set the backlight to 100%.
3. Tap a third time to set the backlight to off.
Adjust the "On" Time of the Backlight
The on time of the backlight refers to the time that the light remains
on during inactive use. Any movement within this time period resets
the internal backlight on timer. The on time of the backlight can be
configured for one minute, five minutes or ten minutes, with the
default setting being one minute. Although it is set for one minute,
the backlight will not turn off while the level is being moved.
1. With the level powered on, tap
configure the backlight on time.
2. The LCD displays will either display "1on", "5on" or "10on"
depending on how the unit was previously configured.
3. Tap to advance the on time to the next setting.
4. Continue to tap
5. Note: Once you have entered this configuration mode, three
seconds of inactivity will revert the display back to normal
measuring mode.
Adjust the Volume
The level's volume can be changed by pressing and holding
level will continue to scroll through the volume options of hi, low
and off until you release the button.
Set the Hold Feature to Freeze the LCD Displays or to Set
Reference Values
The main display and top-read display, including the current
measurement reading, can be frozen while you move the level. This
12
and
until you've reached your desired setting.
simultaneously to
. The
