Johnson Level & Tool 40-6060 Instruction Manual

6” magnetic digital level
Hide thumbs

Advertisement

Quick Links

Download this manual
4595H-English_Manuals 4/8/11 9:31 AM Page 1
6 Magnetic Digital Level
Model No. 40-6060
Instruction Manual
Congratulations on your choice of this 6 Magnetic Digital Level. We
suggest you read this instruction manual thoroughly before using the
instrument. Save this instruction manual for future use.
©2011 Johnson Level & Tool - Rev. 1
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the 40-6060 and is the answer not in the manual?

Questions and answers

Related Manuals for Johnson Level & Tool 40-6060

Summary of Contents for Johnson Level & Tool 40-6060

  • Page 1 4595H-English_Manuals 4/8/11 9:31 AM Page 1 6 Magnetic Digital Level Model No. 40-6060 Instruction Manual Congratulations on your choice of this 6 Magnetic Digital Level. We suggest you read this instruction manual thoroughly before using the instrument. Save this instruction manual for future use.

  • Page 2: Table Of Contents

    4595H-English_Manuals 4/8/11 9:31 AM Page 2 Table of Contents 1. Kit Contents Self-Check and Calibration 2. Features and Functions Technical Specifications 3. Location of Parts/Components Care and Handling 4. Operating Instructions Product Warranty 5. Using the Product 1. Kit Contents Description Qty.

  • Page 3: Location Of Parts/Components

    4595H-English_Manuals 4/8/11 9:31 AM Page 3 3. Location of Part/Components LCD Display Battery Compartment ©2011 Johnson Level & Tool - Rev. 1...

  • Page 4: Operating Instructions

    4595H-English_Manuals 4/8/11 9:31 AM Page 4 4. Operating Instructions IMPORTANT: It is the responsibility of the user to verify the calibration of the instrument before each use. Battery Installation 1. Make sure the instrument is turned off. 2. Turn the battery compartment cover screw counter-clockwise to remove the cover.

  • Page 5: Using The Product

    4595H-English_Manuals 4/8/11 9:31 AM Page 5 5. Using the Product Key Guide Display Power On/Off Zero Key/ Hold Key Mode Key Horn There are four key-presses in this instrument, they are (from right to left): power on/off key, mode key, zero calibration/horn key and the hold key.
  • Page 6 4595H-English_Manuals 4/8/11 9:31 AM Page 6 Horn Function Push the Zero/Horn key once to turn on the horn (symbol should be displayed). Push again to turn off. Horn will start a slow beep at 10º or 17.5% and beep faster the closer you get to 0º or 0%. Once the instrument hits 0º...
  • Page 7 4595H-English_Manuals 4/8/11 9:31 AM Page 7 The figure below shows the left side of the digital level needs to be moved up to achieve level. Shows that the digital level is level. Shows the measurement of the slope. ©2011 Johnson Level & Tool - Rev. 1...
  • Page 8 4595H-English_Manuals 4/8/11 9:31 AM Page 8 6. Self-Check and Calibration IMPORTANT: It is the responsibility of the user to verify the calibration of the instrument before each use. Horizontal Accuracy Check 1. Turn on the digital level and put it on a smooth and level surface as shown in figure 1.
  • Page 9 4595H-English_Manuals 4/8/11 9:31 AM Page 9 Vertical Accuracy Check 1. Turn on the digital level and put it on a smooth and vertical plane as shown in figure 5. Wait 10 seconds until the data reading is stable and then record the angle degree. 2.
  • Page 10 4595H-English_Manuals 4/8/11 9:31 AM Page 10 Figure 9 Figure 10 3. Turn the unit over, still on the same plane making it upside down, as in figure 11, then press the Zero key until the LCD displays -0-. Figure 11 Figure 12 4.
  • Page 11 4595H-English_Manuals 4/8/11 9:31 AM Page 11 Vertical Calibration 1. Turn on the instrument and put it on a smooth and vertical sur- face, figure 13. The two side surfaces of the benchmark should be as parallel as possible, such as glass door or win- dow.

  • Page 12: Technical Specifications

    4595H-English_Manuals 4/8/11 9:31 AM Page 12 7. Technical Specifications Accuracy ±0.1º for 0º and 90º, and ±2º for 1º and 89º Working Range 0º to 90º Power Supply 3 “AAA” alkaline batteries Battery Life Approx. battery life 100 hours continuous use Dimensions 6.14"...

  • Page 13: Care And Handling

    4595H-English_Manuals 4/8/11 9:31 AM Page 13 8. Care and Handling Avoid exposing unit to shock vibrations and extreme temperatures. • Before moving or transporting the unit, make sure that the unit • is turned off. Remove the batteries when storing the unit for an extended time •...

  • Page 14: Product Warranty

    4595H-English_Manuals 4/8/11 9:31 AM Page 14 9. Product Warranty Johnson Level & Tool offers a one year limited warranty on each its products. You can obtain a copy of the limited warranty for a Johnson Level & Tool product by contacting Johnson Level & Tool's Customer Service Department as provided below or by visiting us online at www.johnsonlevel.com.
  • Page 15 4595H-English_Manuals 4/8/11 9:31 AM Page 15 ©2011 Johnson Level & Tool - Rev. 1...
  • Page 16 4595H-English_Manuals 4/8/11 9:31 AM Page 16 ©2011 Johnson Level & Tool - Rev. 1...
