- Page 1 6.5'' Digital Level Model No. 1455-0000 Instruction Manual Congratulations on your choice of this Digital Level. We suggest you read this instruction manual thoroughly before using the instrument. Save this instruction manual for future use. ©2013 Johnson Level & Tool...
-
Page 2: Table Of Contents
Table of Contents 1. Kit Contents 6. Using the Product 2. Features and Functions 7. Technical Specifications 3. Location of Parts/Components 8. Care and Handling 4. Operating Instructions 9. Product Warranty 5. Calibration 1. Kit Contents Description Qty. 6.5" Digital Level “AAA”... -
Page 3: Location Of Parts/Components
3. Location of Parts/Components LCD Display Battery Cover ©2013 Johnson Level & Tool... -
Page 4: Operating Instructions
4. Operating Instructions IMPORTANT: It is the responsibility of the user to verify the calibration of the instrument before each use. Battery Installation 1. Make sure the digital level is turned off. 2. Open the battery compartment. Remove the old batteries and install 2 “AAA”... -
Page 5: Calibration
5. Calibration IMPORTANT: It is the responsibility of the user to verify the calibration of the instrument before each use. 1. Press the On/Off and C button at the same time to enter calibration mode. The LCD will display - - - -. 2. - Page 6 3. Press the On/Off button once, the - - - - symbol on the LCD will begin to flash as shown in picture 2. Pic. 2 4. The LCD will display - - 2 - - (see picture 3). Pic. 3 5.
-
Page 7: Using The Product
6. Using the Product LCD Display Hold Button On/Off Button Degree/Percent Calibrate/Absolute/ Mode Button Relative Button There are four buttons on this instrument. They are (from left to right): On/Off Button Calibrate/Absolute/Relative Button Degree/Percent Mode Button Hold Button ©2013 Johnson Level & Tool... - Page 8 ON/OFF ON/OFF Button Push this button once to turn the unit on. Push this button again to turn the unit off. Calibrate/Absolute/Relative Button In calibration mode Push the On/Off button to toggle through the calibration procedure (see calibration in section 5). In measure mode Push the C button to change from Absolute to Relative modes.
- Page 9 Degree/Percent Mode Button With the unit turned on and in either relative or absolute mode, push this button to toggle between: Degree or percent HOLD Hold Button To take a measurement in an unreadable position, a position where the LCD can not be seen, or, if you want to lock the LCD reading in place while recording the reading, use the Hold Button.
- Page 10 Directional Arrows When the right end of the unit is higher than the left end, the left arrowhead points downward and the right arrowhead points upward. Absolute & Relative Modes The angle Absolute Mode ° readout is 25 in Absolute With the digital level calibrated Mode.
-
Page 11: Technical Specifications
7. Technical Specifications Accuracy: ± 0.1º for 0º and 90º, and ± 0.2º for all others Resolution: 0.1º Working Range: 4 x 90º Power Supply: 2 “AAA” alkaline batteries (included) Battery Life: Approximately 100 hours of continuous use Auto Shut Down Time: After approx. -
Page 12: Product Warranty
• Keep the unit dry and clean. Remove any moisture or dirt with a soft, dry cloth. • Do not use harsh chemicals, strong detergents or cleaning solvents to clean the unit. 9. Product Warranty Johnson Level & Tool offers a one year limited warranty on each its products.
