8185H-English_Manuals 8/8/14 11:36 AM Page 1
Self-Leveling Ultra-Bright Cross-Line Laser
Model No. 40-6625
Instruction Manual
Congratulations on your choice of this Self-Leveling Cross-Line Laser.
We suggest you read this instruction manual thoroughly before using
the instrument. Save this instruction manual for future use.
This is a Class IIIa laser tool and is manufactured to comply with
CFR 21, parts 1040 .10 and 1040 .11 as well as international safety
rule IEC 285.
©2014 Johnson Level & Tool - Rev. 3
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 40-6625 and is the answer not in the manual?

Questions and answers

Summary of Contents for Johnson Level & Tool 40-6625

  • Page 1 8185H-English_Manuals 8/8/14 11:36 AM Page 1 Self-Leveling Ultra-Bright Cross-Line Laser Model No. 40-6625 Instruction Manual Congratulations on your choice of this Self-Leveling Cross-Line Laser. We suggest you read this instruction manual thoroughly before using the instrument. Save this instruction manual for future use.
  • Page 2: Table Of Contents

    5. Location of Parts/Components 13. Warranty Registration 6. Operating Instructions 14. Accessories 7. Using the Product 15. Trouble Shooting 1. Kit Contents Description for Model 40-6625 Qty. Self-Leveling Cross Line Laser Multi-Functional Elevating Magnetic Base “AA” Alkaline Batteries Mounting Strap Magnetic Target...
  • Page 3: Safety Instructions

    8185H-English_Manuals 8/8/14 11:36 AM Page 3 3. Safety Instructions Please read and understand all of the following instructions, prior to using this tool. Failure to do so, may void the warranty. IMPORTANT ATTENTION • Read all instructions prior to operating this laser tool. Do not remove any labels from tool. •...
  • Page 4: Location/Content

    8185H-English_Manuals 8/8/14 11:36 AM Page 4 DANGER! Class IIIa Laser Product Max. Power Output: Wavelength: 625-645nm THIS TOOL EMITS LASER RADIATION. DO NOT STARE INTO BEAM. AVOID DIRECT EYE EXPOSURE. 4. Location/Content of Warning Labels ©2014 Johnson Level & Tool - Rev. 3...
  • Page 5: Location Of Parts/Components

    8185H-English_Manuals 8/8/14 11:36 AM Page 5 5. Location of Part/Components Manual mode button Instrument Manual Mode LED Power LED Laser Output Window On/Off Switch Window Frame Self-Calibrate Rubber Co-Molded Screw/Plug Housing Battery Cover Screw Side Self-Calibrate Screw/Plug Battery Cover 1/4" – 20 thread 5/8"...
  • Page 6: Operating Instructions

    8185H-English_Manuals 8/8/14 11:36 AM Page 6 Multi-Functional Elevating Magnetic Base Wall Screw Hang Hole Locking Knob 1/4" thread Magnets 5/8" thread Laser Attachment Wheel 1/4" thread Strap Slots 6. Operating Instructions IMPORTANT: It is the responsibility of the user to verify the calibration of the instrument before each use.
  • Page 7: Using The Product

    8185H-English_Manuals 8/8/14 11:36 AM Page 7 Note: • Pay attention to the polarity of the batteries. • Used (discharged) batteries are hazardous waste and should be disposed of properly. • If the power indicator light is flashing, the batteries are low and should be changed soon.
  • Page 8 8185H-English_Manuals 8/8/14 11:36 AM Page 8 Manual Mode Operating Instructions 1. Locate the Manual Mode Button (fig. 3) on the side of the laser, above the on/off switch. 2. When the laser is turned on, push the button once to engage the Manual Mode Feature.
  • Page 9: Self-Check & Fine Calibration

    8185H-English_Manuals 8/8/14 11:36 AM Page 9 8. Self-Check & Fine Calibration IMPORTANT: It is the responsibility of the user to verify the calibration of the instrument before each use. 1. Set the laser on a level flat head tripod centered between two walls (marked 1 &...
  • Page 10 8185H-English_Manuals 8/8/14 11:36 AM Page 10 Calibration Re-calibration can be performed as described below. 1. Use a level to mark a horizontal reference line on the wall. 2. Power on the unit to compare the projected horizontal line with its references. Compensator has to be locked before making calibration adjustments.
  • Page 11: Technical Specifications

    8185H-English_Manuals 8/8/14 11:36 AM Page 11 9. Technical Specifications Laser Wavelength 635nm±10 Laser Classification Class IIIa Maximum Power Output Accuracy ±1/8"/35 ft. (±3mm/10m) Interior Range Up to 150 ft. (45m) depending upon light conditions Self-Leveling Range ± 5° Power Supply 3 “AA”...
  • Page 12: Application Demonstrations

    8185H-English_Manuals 8/8/14 11:36 AM Page 12 10. Application Demonstrations Laying tile Fixing cabinets Fixing doors and windows Setting pipelines Installing partitions Installing baseboards Hanging pictures Dormer installation ©2014 Johnson Level & Tool - Rev. 3...
  • Page 13: Care And Handling

    8185H-English_Manuals 8/8/14 11:36 AM Page 13 11. Care and Handling • This laser unit is a precision tool that must be handled with care. • Avoid exposing unit to shock vibrations and extreme temperatures. • Before moving or transporting the unit, make sure that the unit is turned off. •...
  • Page 14: Warranty Registration

    8185H-English_Manuals 8/8/14 11:36 AM Page 14 NOTE: The user is responsible for the proper use and care of the product. It is the responsibility of the user to verify the calibration of the instrument before each use. For further assistance, or if you experience problems with this product that are not addressed in this instruction manual, please contact our Customer Service Dept.
  • Page 15: Accessories

    8185H-English_Manuals 8/8/14 11:36 AM Page 15 14. Accessories Johnson ® accessories are available for purchase through authorized Johnson ® dealers. Use of non-Johnson ® accessories will void any applicable limited warranty and there will be NO WARRANTY. If you need any assistance in locating any accessories, please contact our Customer Service Department.
  • Page 16: Trouble Shooting

    8185H-English_Manuals 8/8/14 11:36 AM Page 16 15. Trouble Shooting • If the unit does not turn on, check the battery polarity or install new batteries and clean the battery terminals. • If the laser does not illuminate, check the battery polarity or install new alkaline batteries and clean the battery terminals.
