RKC INSTRUMENT CB100 Instruction Manual page 35

Name
Heater break alarm 1
setting
See *1.
Heater break alarm 2
setting
See *2.
Control loop break alarm
setting
See *1, *3.
LBA deadband
See *1, *3.
Autotuning (AT)
Self-tuning (ST)
See *5.
Heat-side proportional
band
Integral time
IMCB03-E3
Iden-
Data range
tifier
A3 0.0 to 100.0 A
A4 0.0 to 100.0 A
A5 0.1 to 200.0 min.
(0 can not be set.)
Temperature input:
A6
0 to 9999 !C [!F]
Voltage/current inputs:
0 to 100 % of span
G1 0: Autotuning (AT) end or
suspension
1: Autotuning (AT) start
*Change to "0" automatically at
the end of Autotuning.
G2 0: Self-tuning (ST) suspension
1: Self-tuning (ST) start
P1 Temperature input:
1 (0.1) to span or
9999 (999.9) !C [!F]
Voltage/current inputs :
0.1 to 100.0 % of span
(ON/OFF action control when set
to 0 or 0.0.)
*Cannot be set while the self-tuning
(ST) function is activated.
Only polling can be made.
1 to 3600 sec (0: PD control)
I1
*Cannot be set while the self-tuning
(ST) function is activated.
Only polling can be made.
5. COMMUNICATION IDENTIFIER
Factory set
value
0.0
0.0
8.0
0
0
0
Temperature
input:
30 (30.0)
Voltage/
current
inputs: 3.0
240
Continued on the next page.
Attribute
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
29
