  • Page 1 Limit Controller CB100L/CB900L Initial Setting Manual IMCB10-E1 RKC INSTRUMENT INC. ®...
  • Page 2 RKC assumes no responsibility for any of the following damage which the user or third party may suffer. (1) Damage incurred as a result of using this product. (2) Damage caused by product failure which cannot be predicted by RKC. (3) Other indirect damage. All Rights Reserved, Copyright  1998, RKC INSTRUMENT INC.
  • Page 3 INTRODUCTION Before using this instrument, please carefully read this manual for its correct use. In addition, after reading the manual keep it available easily anytime. USERS OF THIS MANUAL This manual is written mainly for personnel who have a fundamental knowledge of electricity as well as control.
  • Page 4 NOTES ON INDICATIONS The following indications are used in this manual to ensure the safe, correct use of the CB100L/CB900L. SIGNAL WORDS : Where there are possible dangers such as electric shock, fire(burns), etc. Which...
  • Page 5 Name and number of this instruction manual : Limit Controller CB100L/CB900L Initial Setting Manual Name : Manual number : IMCB10-E1 Revisions Date of revision Manual number Reason for revision IMCB10-E1 October 5, 1998 The first edition issue i - 3...

  • Page 6: Table Of Contents

    CONTENTS 1. TRANSFER TO MODE ..............1 1.1 Transfer to initialization mode................1 1.2 End of initialization mode.................3 2. PROCEDURE FOR SETTING............4 2.1 Display flowcharts in initialization mode............4 2.2 Procedure for setting each parameter .............5 2.3 Details of parameters in initialize code 0(Cod=0) ..........7 2.4 Details of parameters in initialize code 1 (Cod=1) .........12 2.5 Details of parameters in initialize code 2 (Cod=2) .........18 3.

  • Page 7: Transfer To Mode

    Press the SET key for 2 sec with the instrument set to PV/SV display mode to change the instrument to parameter setting mode. *For details on parameter setting mode, see the CB100L/CB900L Instruction Manual. [IMCB08-E ] Press the SET key to change to the set data lock function display screen.
  • Page 8 1. TRANSFER TO MODE Press the SET key to change to the next parameter. Thus, the data in initialization mode is unlocked. Alarm 1 setting value PV PV PV PV SV SV SV SV ALM2 EXCD ALM1 *In the above figure, the alarm 1 (ALM1) setting value is displayed. However, the parameter to be displayed varies depending on the specification.

  • Page 9: End Of Initialization Mode

    1. TRANSFER TO MODE 1.2 End of initialization mode Transfer to "initialize code selection" after each parameter is set. Simultaneously keep pressing both the SET and <RST keys for 2 sec in the "Initialize code selection" state to transfer to "PV/SV display mode." Press the SET key for 2 sec in the "PV/SV display mode"...

  • Page 10: Procedure For Setting

    2.PROCEDURE FOR SETTING 2. PROCEDURE FOR SETTING If the instrument is changed to initialization mode, the symbol (Cod) for selecting the initialize code is displayed first. (Initializing items are classified into 3 initialize code groups in initialization mode.) Enter the initialize code corresponding to the parameter to be chanted, and then select the parameter to be changed by pressing the SET key.

  • Page 11: Procedure For Setting Each Parameter

    2.PROCEDURE FOR SETTING 2.2 Procedure for setting each parameter [Example of changing the setting] When the display unit shows "Limit action type selection (SL6)" in initialize code "0", the following procedure is for changing the limit action type from "high limit action" to "low limit action." Change the instrument to the initialize code selection display.
  • Page 12 2.PROCEDURE FOR SETTING Press the <RST key to move the brightly lit digit of the set value (SV) display unit to the hundreds digit. The brightly lit digit moves as follows every time the <RST key is pressed. Press the UP key to enter "1" in the hundreds digit of the set value (SV) display unit. Limit action type selection Set value 0 : Limit action (high limit)

  • Page 13: Details Of Parameters In Initialize Code 0(Cod=0)

    2.PROCEDURE FOR SETTING Parameter display position Measured value (PV) display unit shows parameter No. (character). Input the numerical value in the set value (SV) display unit. Set value *Note that the relevant digit used differs depending on the parameter. The figure at the above is for selects the "Limit action (low limit)" in "SL6 (Limit action type selection)." The details of parameters in each initialize code group are described in the following.
  • Page 14 2.PROCEDURE FOR SETTING SL2 (Engineering unit selection) CAUTIONS For the input type of "Voltage/current input," even if the unit is set, it is ineffective. Any digits other than the units digit are not used. As malfunction may result, do not change any of these digits.
  • Page 15 2.PROCEDURE FOR SETTING (4) SL4 (Alarm 1 type selection) CAUTION Instrument without the alarm 1 (ALM1) is set to "0000." Factory set value varies depending on the instrument specification. Set value Description Alarm 1 (ALM1) not provided Alarm 1 (ALM1) type selection Deviation high alarm Deviation high/low alarm Process high alarm...
  • Page 16 2.PROCEDURE FOR SETTING (6) SL6 (Limit action type selection) CAUTION The units digit is not used. As malfunction may result, do not change this digit. Factory set value : "0000" Set value Description Fixed Limit action output turned ON at the time of power Selects the limit Limit actin output turned OFF at the time of power ON action type and Limit action (high limit)
  • Page 17 2.PROCEDURE FOR SETTING (8) SL8 (Special specification selection 2) CAUTION The thousands and hundreds digits are not used. As malfunction may result, do not change these digits. Factory set value : "0011" Set value Description Limit action output (Energized output) Selects limit action output Limit action output (De-energized output) energized/de-energized.

  • Page 18: Details Of Parameters In Initialize Code 1 (Cod=1)

    2.PROCEDURE FOR SETTING (11) SL11 (For manufacturer's [RKC's] own use) CAUTION Do not change it, as it is used to adjust the instrument. 2.4 Details of parameters in initialize code 1 (Cod=1) (1) SLH (Setting limiter [high limit] ) CAUTIONS Set the limiter by referring to "Input range table"...
  • Page 19 2.PROCEDURE FOR SETTING (2) SLL (Setting limiter [low limit] ) CAUTIONS Set the limiter by referring to "Input range table." (P.15) Limiter setting becomes SLH SLL. Setting method Press the <RST key to move the digit, then enter the low limit value of input range by pressing the UP or DOWN key.
  • Page 20 2.PROCEDURE FOR SETTING Input range table Thermocouple input Type Input range Type Input range 0 to 200 °C 400 to 1800 °C 0 to 400 °C 0 to 1820 °C 0 to 600 °C 800 to 3200 °F 0 to 800 °C 0 to 3308 °F 0 to 1000 °C 0 to 800 °C...
  • Page 21 2.PROCEDURE FOR SETTING Type Input range 0 to 400 °C 0 to 800 °C 0 to 800 °F 0 to 1600 °F *1 ⋅⋅⋅⋅ 0 to 399 °C/0 to 799 °F : Accuracy is not guaranteed. *2 ⋅⋅⋅⋅ -199.9 to -100.0 °C/-199.9 to -158.0 °F : Accuracy is not guaranteed. RTD input Type Input range...
  • Page 22 2.PROCEDURE FOR SETTING Voltage input Type Input range 0 to 5 V DC 0.0 to 100.0 % 0 to 10 V DC* 1 to 5 V DC *For the 0 to 10 V DC (Z-1010 specification), no input type cannot be changed as the hardware differs.
  • Page 23 2.PROCEDURE FOR SETTING (3) PGdP (Setting the position of decimal point) CAUTIONS The set position of the decimal point is displayed only for current or voltage input. Any digits other than the units digit are not used. As malfunction may result, do not change any of these digits.

  • Page 24: Details Of Parameters In Initialize Code 2 (Cod=2)

    2.PROCEDURE FOR SETTING 2.5 Details of parameters in initialize code 2 (Cod=2) Parameters in initialize code 2 are only displayed. (1) TCJ (Holding peak ambient temperature) The maximum ambient temperature on the rear terminal board of the instrument is stored and displayed on the set value (SV) display unit.

  • Page 25: Communication Initialize Identifier

    List of communication initialize identifiers NOTES Note that there are identifiers which cannot be communicated depending n the specification. For details on the structure of communication data, see the CB100L/CB900L Communication Instruction Manual. [IMCB09-E ] The number of digits is 6 for all data.
  • Page 26 3.COMMUNICATION INITIALIZE IDENTIFIER Name Data range To vary Setting limiter (high limit) [SLH] XV See "Input range table" depending on (P.14, 15, 16) the shipment Setting limiter (low limit) [SLL] Setting the position of decimal point XU 0 : No digit below decimal point [PGdP] 1 : 1 digit below decimal point 2 : 2 digits below decimal point...
  • Page 27 3.COMMUNICATION INITIALIZE IDENTIFIER Input type Setting range Set value Pt100 Ω (JIS/IEC) -199.9 to +649.0 °C (-199.9 to +99.9 °F) RTD input JPt100 Ω (JIS) -199.9 to +649.0 °C (-199.9 to +999.9 °F) (RTD) Voltage input 0 to 5V DC 0.0 to 100.0 % 1 to 5V DC 0.0 to 100.0 %...
  • Page 28 3.COMMUNICATION INITIALIZE IDENTIFIER *5 ⋅⋅⋅⋅ 0 : Alarm 1 (Energized alarm), Alarm 2 (Energized alarm) 1 : Alarm 1 (De-energized alarm), Alarm 2 (Energized alarm) 2 : Alarm 1 (Energized alarm), Alarm 2 (De-energized alarm) 3 : Alarm 1 (De-energized alarm), Alarm 2 (De-energized alarm) 4 : Alarm 1 (Energized alarm, Z-124 specification provided), Alarm 2 (Energized alarm) 5 : Alarm 1 (De-energized alarm, Z-124 specification provided), Alarm 2 (Energized alarm) 6 : Alarm 1 (Energized alarm, Z-124 specification provided), Alarm 2 (De-energized alarm)
  • Page 29 All Rights Reserved, Copyright  1998, RKC INSTRUMENT INC.
  • Page 30 RKC INSTRUMENT INC. HEAD OFFICE: 16-6, KUGAHARA 5-CHOME, OHTA-KU TOKYO 146-8515 JAPAN PHONE: 03-3751-9799 (+81 3 3751 9799) E-mail: info@rkcinst.co.jp IMCB10-E1 OCT.1998...
