Temperature Controller
MODBUS SIO Driver
1
System Configuration....................................................................................................... 3
2
Selection of External Device ............................................................................................ 9
3
Example of Communication Setting ............................................................................... 10
4
Setup Items .................................................................................................................... 70
5
Cable Diagram ............................................................................................................... 75
6
Supported Device......................................................................................................... 144
7
Device Code and Address Code.................................................................................. 155
8
Error Messages............................................................................................................ 157
1
RKC Instrument Inc.

Advertisement

loading
Need help?

Need help?

Do you have a question about the CB Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for RKC INSTRUMENT CB Series

Summary of Contents for RKC INSTRUMENT CB Series

  • Page 1: Table Of Contents

    RKC Instrument Inc. Temperature Controller MODBUS SIO Driver System Configuration....................... 3 Selection of External Device .................... 9 Example of Communication Setting ................10 Setup Items ........................70 Cable Diagram ....................... 75 Supported Device......................144 Device Code and Address Code.................. 155...
  • Page 2 Temperature Controller MODBUS SIO Driver Introduction This manual describes how to connect the Display and the External Device (target Temperature Controller). In this manual, the connection procedure will be described by following the below sections: System Configuration "1 System Configuration" (page 3) This section shows the types of External Devices which can be connected and SIO type.

  • Page 3: System Configuration

    Temperature Controller MODBUS SIO Driver System Configuration The system configuration in the case when the External Device of RKC Instrument Inc. and the Display are connected is shown. Setting Cable Series Link I/F SIO Type Example Diagram CB100 -5 / Z-1021...
  • Page 4 Temperature Controller MODBUS SIO Driver Setting Cable Series Link I/F SIO Type Example Diagram Terminal block Setting Cable RS422/ MA900-4 - 6/ on the Example 8 Diagram 3 485(2 wire) controller (page 24) (page 81) Terminal block Setting Cable RS422/ MA900 MA900-4 - 7/...
  • Page 5 Temperature Controller MODBUS SIO Driver Setting Cable Series Link I/F SIO Type Example Diagram Setting Cable Connector on RS422/ H-PCP-J- 4 -D* Example 20 Diagram 4 the controller 485(4 wire) (page 48) (page 87) Setting Cable Connector on RS422/ H-PCP-J- 5 -D* Example 21 Diagram 5 the controller...
  • Page 6 Temperature Controller MODBUS SIO Driver Connection Configuration • 1:1 Connection Display External Drive • 1:n Connection External External External Drive Drive Drive Display Maximum number of connections: 16 units • 1:n Connection (For the SRZ (Z-TIO), SRZ (Z-DIO), and SRZ (Z-CT) Series) Display External Drive Maximum number of connections: 16 units...
  • Page 7 Temperature Controller MODBUS SIO Driver IPC COM Port When connecting IPC with an External Device, the COM port used depends on the series and SIO type. Please refer to the IPC manual for details. Usable port Usable Port Series RS-232C RS-422/485(4 wire) RS-422/485(2 wire) COM1...
  • Page 8 Temperature Controller MODBUS SIO Driver DIP Switch setting: RS-422/485 (4 wire) DIP Switch Setting Description Reserved (always OFF) SIO type: RS-422/485 Output mode of SD (TXD) data: Always output Terminal resistance (220Ω) insertion to SD (TXD): None Terminal resistance (220Ω) insertion to RD (RXD): None Short-circuit of SDA (TXA) and RDA (RXA): Not available Short-circuit of SDB (TXB) and RDB (RXB): Not available RS (RTS) Auto control mode: Disabled...

  • Page 9: Selection Of External Device

    Setup Items Setup Description Maker Select the maker of the External Device to be connected. Select "RKC Instrument Inc.". Select a model (series) of the External Device to be connected and connection method. Select "Temperature Controller MODBUS SIO". Check the External Device which can be connected in "Temperature Controller MODBUS Driver SIO"...

  • Page 10: Example Of Communication Setting

    Temperature Controller MODBUS SIO Driver Example of Communication Setting Examples of communication settings of the Display and the External Device, recommended by Digital Electronics Corp., are shown. Setting Example 1 Settings of GP-Pro EX Communication Settings To display the setting screen, select [Device/PLC Settings] from [System setting window] in workspace. GP-Pro EX Device/PLC Connection Manual...
  • Page 11 Temperature Controller MODBUS SIO Driver Device Setting To display the setting screen, click ([Setting]) of the External Device you want to set from [Device-Specific Settings ] of [Device/PLC Settings ]. Settings of External Device Use the SET key, shift key, down key and up key on the front of the Temperature Controller for communication settings of the External Device.
  • Page 12 Temperature Controller MODBUS SIO Driver Setting Example 2 Settings of GP-Pro EX Communication Settings To display the setting screen, select [Device/PLC Settings] from [System setting window] in workspace. GP-Pro EX Device/PLC Connection Manual...
  • Page 13 Temperature Controller MODBUS SIO Driver Device Setting To display the setting screen, click ([Setting]) of the External Device you want to set from [Device-Specific Settings ] of [Device/PLC Settings ]. Settings of External Device Use the SET key, shift key, down key and up key on the front of the Temperature Controller for communication settings of the External Device.
  • Page 14 Temperature Controller MODBUS SIO Driver Setting Example 3 Settings of GP-Pro EX Communication Settings To display the setting screen, select [Device/PLC Settings] from [System setting window] in workspace. GP-Pro EX Device/PLC Connection Manual...
  • Page 15 Temperature Controller MODBUS SIO Driver Device Setting To display the setting screen, click ([Setting]) of the External Device you want to set from [Device-Specific Settings ] of [Device/PLC Settings ]. Settings of External Device Use the SET key, shift key, down key and up key on the front of the Temperature Controller for communication settings of the External Device.
  • Page 16 Temperature Controller MODBUS SIO Driver Setting Example 4 Settings of GP-Pro EX Communication Settings To display the setting screen, select [Device/PLC Settings] from [System setting window] in workspace. GP-Pro EX Device/PLC Connection Manual...
  • Page 17 Temperature Controller MODBUS SIO Driver Device Setting To display the setting screen, click ([Setting]) of the External Device you want to set from [Device-Specific Settings ] of [Device/PLC Settings ]. Settings of External Device Use the SET key, shift key, down key and up key on the front of the Temperature Controller for communication settings of the External Device.
  • Page 18 Temperature Controller MODBUS SIO Driver Setting Example 5 Settings of GP-Pro EX Communication Settings To display the setting screen, select [Device/PLC Settings] from [System setting window] in workspace. GP-Pro EX Device/PLC Connection Manual...
  • Page 19 Temperature Controller MODBUS SIO Driver Device Setting To display the setting screen, click ([Setting]) of the External Device you want to set from [Device-Specific Settings ] of [Device/PLC Settings ]. Settings of External Device Use the SET key, shift key, down key and up key on the front of the Temperature Controller for communication settings of the External Device.
  • Page 20 Temperature Controller MODBUS SIO Driver Setting Example 6 Settings of GP-Pro EX Communication Settings To display the setting screen, select [Device/PLC Settings] from [System setting window] in workspace. GP-Pro EX Device/PLC Connection Manual...
  • Page 21 Temperature Controller MODBUS SIO Driver Device Setting To display the setting screen, click ([Setting]) of the External Device you want to set from [Device-Specific Settings ] of [Device/PLC Settings ]. Settings of External Device Use the SET key, shift key, down key and up key on the front of the Temperature Controller for communication settings of the External Device.
  • Page 22 Temperature Controller MODBUS SIO Driver Setting Example 7 Settings of GP-Pro EX Communication Settings To display the setting screen, select [Device/PLC Settings] from [System setting window] in workspace. GP-Pro EX Device/PLC Connection Manual...
  • Page 23 Temperature Controller MODBUS SIO Driver Device Setting To display the setting screen, click ([Setting]) of the External Device you want to set from [Device-Specific Settings ] of [Device/PLC Settings ]. Settings of External Device Use the SET key, shift key, down key and up key on the front of the Temperature Controller for communication settings of the External Device.
  • Page 24 Temperature Controller MODBUS SIO Driver Setting Example 8 Settings of GP-Pro EX Communication Settings To display the setting screen, select [Device/PLC Settings] from [System setting window] in workspace. GP-Pro EX Device/PLC Connection Manual...
  • Page 25 Temperature Controller MODBUS SIO Driver Device Setting To display the setting screen, click ([Setting]) of the External Device you want to set from [Device-Specific Settings ] of [Device/PLC Settings ]. Settings of External Device Use the SET key, shift key, down key and up key on the front of the Temperature Controller for communication settings of the External Device.
  • Page 26 Temperature Controller MODBUS SIO Driver Setting Example 9 Settings of GP-Pro EX Communication Settings To display the setting screen, select [Device/PLC Settings] from [System setting window] in workspace. GP-Pro EX Device/PLC Connection Manual...
  • Page 27 Temperature Controller MODBUS SIO Driver Device Setting To display the setting screen, click ([Setting]) of the External Device you want to set from [Device-Specific Settings ] of [Device/PLC Settings ]. Settings of External Device Use the SET key, shift key, down key and up key on the front of the Temperature Controller for communication settings of the External Device.
  • Page 28 Temperature Controller MODBUS SIO Driver 3.10 Setting Example 10 Settings of GP-Pro EX Communication Settings To display the setting screen, select [Device/PLC Settings] from [System setting window] in workspace. GP-Pro EX Device/PLC Connection Manual...
  • Page 29 Temperature Controller MODBUS SIO Driver Device Setting To display the setting screen, click ([Setting]) of the External Device you want to set from [Device-Specific Settings ] of [Device/PLC Settings ]. Settings of External Device Use the SET key, shift key, down key and up key on the front of the Temperature Controller for communication settings of the External Device.
  • Page 30 Temperature Controller MODBUS SIO Driver 3.11 Setting Example 11 Settings of GP-Pro EX Communication Settings To display the setting screen, select [Device/PLC Settings] from [System setting window] in workspace. GP-Pro EX Device/PLC Connection Manual...
  • Page 31 Temperature Controller MODBUS SIO Driver Device Setting To display the setting screen, click ([Setting]) of the External Device you want to set from [Device-Specific Settings ] of [Device/PLC Settings ]. Settings of External Device Use the SET key, shift key, down key and up key on the front of the Temperature Controller for communication settings of the External Device.
  • Page 32 Temperature Controller MODBUS SIO Driver 3.12 Setting Example 12 Settings of GP-Pro EX Communication Settings To display the setting screen, select [Device/PLC Settings] from [System setting window] in workspace. GP-Pro EX Device/PLC Connection Manual...
  • Page 33 Temperature Controller MODBUS SIO Driver Device Setting To display the setting screen, click ([Setting]) of the External Device you want to set from [Device-Specific Settings ] of [Device/PLC Settings ]. Settings of External Device Use the SET key, shift key, down key and up key on the front of the Temperature Controller for communication settings of the External Device.
  • Page 34 Temperature Controller MODBUS SIO Driver 3.13 Setting Example 13 Settings of GP-Pro EX Communication Settings To display the setting screen, select [Device/PLC Settings] from [System setting window] in workspace. GP-Pro EX Device/PLC Connection Manual...
  • Page 35 Temperature Controller MODBUS SIO Driver Device Setting To display the setting screen, click ([Setting]) of the External Device you want to set from [Device-Specific Settings ] of [Device/PLC Settings ]. Settings of External Device Use the SET key, shift key, down key and up key on the front of the Temperature Controller for communication settings of the External Device.
  • Page 36 Temperature Controller MODBUS SIO Driver 3.14 Setting Example 14 Settings of GP-Pro EX Communication Settings To display the setting screen, select [Device/PLC Settings] from [System setting window] in workspace. GP-Pro EX Device/PLC Connection Manual...
  • Page 37 Temperature Controller MODBUS SIO Driver Device Setting To display the setting screen, click ([Setting]) of the External Device you want to set from [Device-Specific Settings ] of [Device/PLC Settings ]. Settings of External Device Use the address setting switch on the front of the Temperature Controller and the DIP switch inside the Temperature Controller for communication settings of the External Device.
  • Page 38 Temperature Controller MODBUS SIO Driver 3.15 Setting Example 15 Settings of GP-Pro EX Communication Settings To display the setting screen, select [Device/PLC Settings] from [System setting window] in workspace. GP-Pro EX Device/PLC Connection Manual...
  • Page 39 Temperature Controller MODBUS SIO Driver Device Setting To display the setting screen, click ([Setting]) of the External Device you want to set from [Device-Specific Settings ] of [Device/PLC Settings ]. Settings of External Device Use the address setting switch on the front of the Temperature Controller and the DIP switch inside the Temperature Controller for communication settings of the External Device.
  • Page 40 Temperature Controller MODBUS SIO Driver 3.16 Setting Example 16 Settings of GP-Pro EX Communication Settings To display the setting screen, select [Device/PLC Settings] from [System setting window] in workspace. GP-Pro EX Device/PLC Connection Manual...
  • Page 41 Temperature Controller MODBUS SIO Driver Device Setting To display the setting screen, click ([Setting]) of the External Device you want to set from [Device-Specific Settings ] of [Device/PLC Settings ]. Settings of External Device Use the SET key, shift key, down key and up key on the front of the Temperature Controller for communication settings of the External Device.
  • Page 42 Temperature Controller MODBUS SIO Driver 3.17 Setting Example 17 Settings of GP-Pro EX Communication Settings To display the setting screen, select [Device/PLC Settings] from [System setting window] in workspace. GP-Pro EX Device/PLC Connection Manual...
  • Page 43 Temperature Controller MODBUS SIO Driver Device Setting To display the setting screen, click ([Setting]) of the External Device you want to set from [Device-Specific Settings ] of [Device/PLC Settings ]. Settings of External Device Use the SET key, shift key, down key and up key on the front of the Temperature Controller for communication settings of the External Device.
  • Page 44 Temperature Controller MODBUS SIO Driver 3.18 Setting Example 18 Settings of GP-Pro EX Communication Settings To display the setting screen, select [Device/PLC Settings] from [System setting window] in workspace. GP-Pro EX Device/PLC Connection Manual...
  • Page 45 Temperature Controller MODBUS SIO Driver Device Setting To display the setting screen, click ([Setting]) of the External Device you want to set from [Device-Specific Settings ] of [Device/PLC Settings ]. Settings of External Device Use the slave address setting switch on the front of the Temperature Controller and the DIP switch inside the Temperature Controller for communication settings of the External Device.
  • Page 46 Temperature Controller MODBUS SIO Driver 3.19 Setting Example 19 Settings of GP-Pro EX Communication Settings To display the setting screen, select [Device/PLC Settings] from [System setting window] in workspace. GP-Pro EX Device/PLC Connection Manual...
  • Page 47 Temperature Controller MODBUS SIO Driver Device Setting To display the setting screen, click ([Setting]) of the External Device you want to set from [Device-Specific Settings ] of [Device/PLC Settings ]. Settings of External Device Use the slave address setting switch on the front of the Temperature Controller and the DIP switch inside the Temperature Controller for communication settings of the External Device.
  • Page 48 Temperature Controller MODBUS SIO Driver 3.20 Setting Example 20 Settings of GP-Pro EX Communication Settings To display the setting screen, select [Device/PLC Settings] from [System setting window] in workspace. GP-Pro EX Device/PLC Connection Manual...
  • Page 49 Temperature Controller MODBUS SIO Driver Device Setting To display the setting screen, click ([Setting]) of the External Device you want to set from [Device-Specific Settings ] of [Device/PLC Settings ]. Settings of External Device Use the unit address setting switch on the front of the Temperature Controller and the DIP switch on the side of the Temperature Controller for communication settings of the External Device.
  • Page 50 Temperature Controller MODBUS SIO Driver COM.PORT3 setting switch Settings Description Data bit configuration Speed Communication Protocol Initialization MODBUS mode selection Fixed • Parameters to be set vary depending on the Temperature Controller. Please refer to the manual of the Temperature Controller for more details. GP-Pro EX Device/PLC Connection Manual...
  • Page 51 Temperature Controller MODBUS SIO Driver 3.21 Setting Example 21 Settings of GP-Pro EX Communication Settings To display the setting screen, select [Device/PLC Settings] from [System setting window] in workspace. GP-Pro EX Device/PLC Connection Manual...
  • Page 52 Temperature Controller MODBUS SIO Driver Device Setting To display the setting screen, click ([Setting]) of the External Device you want to set from [Device-Specific Settings ] of [Device/PLC Settings ]. Settings of External Device Use the unit address setting switch on the front of the Temperature Controller and the DIP switch on the side of the Temperature Controller for communication settings of the External Device.
  • Page 53 Temperature Controller MODBUS SIO Driver COM.PORT3 setting switch • Settings Description Data bit configuration Speed Communication Protocol Initialization MODBUS mode selection Fixed • Parameters to be set vary depending on the Temperature Controller. Please refer to the manual of the Temperature Controller for more details. GP-Pro EX Device/PLC Connection Manual...
  • Page 54 Temperature Controller MODBUS SIO Driver 3.22 Setting Example 22 Settings of GP-Pro EX Communication Settings To display the setting screen, select [Device/PLC Settings] from [System setting window] in workspace. GP-Pro EX Device/PLC Connection Manual...
  • Page 55 Temperature Controller MODBUS SIO Driver Device Setting To display the setting screen, click ([Setting]) of the External Device you want to set from [Device-Specific Settings ] of [Device/PLC Settings ]. Settings of External Device Use the unit address setting switch on the front of the Temperature Controller and the DIP switch on the side of the Temperature Controller for communication settings of the External Device.
  • Page 56 Temperature Controller MODBUS SIO Driver 3.23 Setting Example 23 Settings of GP-Pro EX Communication Settings To display the setting screen, select [Device/PLC Settings] from [System setting window] in workspace. GP-Pro EX Device/PLC Connection Manual...
  • Page 57 Temperature Controller MODBUS SIO Driver Device Setting To display the setting screen, click ([Setting]) of the External Device you want to set from [Device-Specific Settings ] of [Device/PLC Settings ]. Settings of External Device Use the unit address setting switch on the front of the Temperature Controller and the DIP switch on the side of the Temperature Controller for communication settings of the External Device.
  • Page 58 Temperature Controller MODBUS SIO Driver 3.24 Setting Example 24 Settings of GP-Pro EX Communication Settings To display the setting screen, select [Device/PLC Settings] from [System setting window] in workspace. GP-Pro EX Device/PLC Connection Manual...
  • Page 59 Temperature Controller MODBUS SIO Driver Device Setting To display the setting screen, click ([Setting]) of the External Device you want to set from [Device-Specific Settings ] of [Device/PLC Settings ]. Settings of External Device Use the unit address setting switch on the front of the Temperature Controller and the DIP switch on the side of the Temperature Controller for communication settings of the External Device.
  • Page 60 Temperature Controller MODBUS SIO Driver 3.25 Setting Example 25 Settings of GP-Pro EX Communication Settings To display the setting screen, select [Device/PLC Settings] from [System setting window] in workspace. GP-Pro EX Device/PLC Connection Manual...
  • Page 61 Temperature Controller MODBUS SIO Driver Device Setting To display the setting screen, click ([Setting]) of the External Device you want to set from [Device-Specific Settings ] of [Device/PLC Settings ]. Settings of External Device Use the unit address setting switch on the front of the Temperature Controller and the DIP switch on the side of the Temperature Controller for communication settings of the External Device.
  • Page 62 Temperature Controller MODBUS SIO Driver 3.26 Setting Example 26 Settings of GP-Pro EX Communication Settings To display the setting screen, select [Device/PLC Settings] from [System setting window] in workspace. GP-Pro EX Device/PLC Connection Manual...
  • Page 63 Temperature Controller MODBUS SIO Driver Device Setting To display the setting screen, click ([Setting]) of the External Device you want to set from [Device-Specific Settings ] of [Device/PLC Settings ]. Settings of External Device Use the unit address setting switch on the front of the Temperature Controller and the DIP switch on the side of the Temperature Controller for communication settings of the External Device.
  • Page 64 Temperature Controller MODBUS SIO Driver 3.27 Setting Example 27 Settings of GP-Pro EX Communication Settings To display the setting screen, select [Device/PLC Settings] from [System setting window] in workspace. GP-Pro EX Device/PLC Connection Manual...
  • Page 65 Temperature Controller MODBUS SIO Driver Device Setting To display the setting screen, click ([Setting]) of the External Device you want to set from [Device-Specific Settings ] of [Device/PLC Settings ]. Settings of External Device Use the unit address setting switch on the front of the Temperature Controller and the DIP switch on the side of the Temperature Controller for communication settings of the External Device.
  • Page 66 Temperature Controller MODBUS SIO Driver 3.28 Setting Example 28 Settings of GP-Pro EX Communication Settings To display the setting screen, select [Device/PLC Settings] from [System setting window] in workspace. GP-Pro EX Device/PLC Connection Manual...
  • Page 67 Temperature Controller MODBUS SIO Driver Device Setting To display the setting screen, click ([Setting]) of the External Device you want to set from [Device-Specific Settings ] of [Device/PLC Settings ]. Settings of External Device Use the unit address setting switch on the front of the Temperature Controller and the DIP switch on the side of the Temperature Controller for communication settings of the External Device.
  • Page 68 Temperature Controller MODBUS SIO Driver 3.29 Setting Example 29 Settings of GP-Pro EX Communication Settings To display the setting screen, select [Device/PLC Settings] from [System setting window] in workspace. GP-Pro EX Device/PLC Connection Manual...
  • Page 69 Temperature Controller MODBUS SIO Driver Device Setting To display the setting screen, click ([Setting]) of the External Device you want to set from [Device-Specific Settings ] of [Device/PLC Settings ]. Settings of External Device Use the unit address setting switch on the front of the Temperature Controller and the DIP switch on the side of the Temperature Controller for communication settings of the External Device.

  • Page 70: Setup Items

    Temperature Controller MODBUS SIO Driver Setup Items Set communication settings of the Display with GP-Pro Ex or in offline mode of the Display. The setting of each parameter must be identical to that of External Device. "3 Example of Communication Setting" (page 10) Setup Items in GP-Pro EX Communication Settings To display the setting screen, select [Device/PLC Settings] from [System setting window] in workspace.
  • Page 71 Temperature Controller MODBUS SIO Driver Setup Items Setup Description Use an integer from 0 to 255 to enter standby time (ms) for the Display from receiving packets Wait To Send to transmitting next commands. Switches RI/VCC of the 9th pin. RI/VCC It is necessary to change RI/5V by changeover switch of IPC when connect with IPC.
  • Page 72 Temperature Controller MODBUS SIO Driver Setup Items in Offline Mode • Refer to the Maintenance/Troubleshooting guide for information on how to enter offline mode or about the operation. Maintenance/Troubleshooting Guide "Offline Mode" • The number of the setup items to be displayed for 1 page in the offline mode depends on the Display in use.
  • Page 73 Temperature Controller MODBUS SIO Driver Setup Items Setup Description Use an integer from 1 to 127 to enter the time (s) for which the Display waits for the Timeout response from the External Device. In case of no response from the External Device, use an integer from 0 to 255 to enter how Retry many times the Display retransmits the command.
  • Page 74 Temperature Controller MODBUS SIO Driver Option To display the setting screen, touch [Device/PLC Settings] from [Peripheral Settings]. Touch the External Device you want to set from the displayed list, and touch [Option]. Setup Items Setup Description Switches RI/VCC of the 9th pin. RI/VCC It is necessary to change RI/5V by changeover switch of IPC when connect with IPC.

  • Page 75: Cable Diagram

    Temperature Controller MODBUS SIO Driver Cable Diagram The cable diagram shown below may be different from the cable diagram recommended by RKC Instrument Inc. Please be assured there is no operational problem in applying the cable diagram shown in this manual.
  • Page 76 Temperature Controller MODBUS SIO Driver External Device side Display side D-Sub 9 Pin (socket) Modular 6 Pin Shield Signal name Signal name RD(RXD) Display SD(TXD) ER(DTR) Shield DR(DSR) RS(RTS) CS(CTS) Display side External Device side Terminal block Modular 6 Pin Shield Signal name Signal name...
  • Page 77 Temperature Controller MODBUS SIO Driver Cable Diagram 2 Display Cable Remarks (Connection Port) COM port conversion adapter by Pro-face CA3-ADPCOM-01 GP3000 (COM1) AGP-3302B (COM2) Terminal block conversion adapter by Pro-face GP-4*01TM (COM1) CA3-ADPTRM-01 (COM2) LT (COM1) User-created cable User-created cable Online adapter by Pro-face CA4-ADPONL-01 Cable length:...
  • Page 78 Temperature Controller MODBUS SIO Driver • 1:1 Connection External Device side COM.PORT1 Display side Modular 6 Pin Shield Termination Termination resistance resistance Signal name Signal name 120Ω + 10% or less 120Ω + 10% or less Display T(B) CA3-ADPCOM-01 T(A) R(B) Termination CA3-ADPTRM-01...
  • Page 79 Temperature Controller MODBUS SIO Driver • 1:1 Connection External Device side COM.PORT1 Display side Shield Modular 6 Pin Termination Termination resistance resistance Signal name Signal name 120Ω + 10% or less 120Ω + 10% or less Display T(B) CA4-ADPONL-01 T(A) R(B) Termination resistance...
  • Page 80 Temperature Controller MODBUS SIO Driver • 1:1 Connection External Device side Display side COM.PORT1 Terminal block Shield Modular 6 Pin Termination resistance Signal name Termination Signal name 120Ω + 10% or less resistance*1 T(B) Display T(A) R(B) Termination resistance R(A) Termination 120Ω...
  • Page 81 Temperature Controller MODBUS SIO Driver Cable Diagram 3 Display Cable Remarks (Connection Port) COM port conversion adapter by Pro-face CA3-ADPCOM-01 GP3000 (COM1) AGP-3302B (COM2) Terminal block conversion adapter by Pro-face GP-4*01TM (COM1) CA3-ADPTRM-01 (COM2) LT (COM1) User-created cable User-created cable Online adapter by Pro-face CA4-ADPONL-01 Terminal block conversion adapter by Pro-face...
  • Page 82 Temperature Controller MODBUS SIO Driver • 1:1 Connection Display side Termination resistance Signal name Shield External Device side 120 Ω (1/2W) Terminal block Display Signal name CA3-ADPCOM-01 Termination T/R(B) resistance 120 Ω (1/2W) T/R(A) CA3-ADPTRM-01 User-created cable • 1: n connection Display side Termination resistance...
  • Page 83 Temperature Controller MODBUS SIO Driver • 1:1 Connection Display side Termination resistance Signal name Shield External Device side 120 Ω (1/2W) Terminal block Display Signal name CA4-ADPONL-01 Termination T/R(B) resistance 120 Ω (1/2W) T/R(A) CA3-ADPTRM-01 User-created cable • 1:n Connection Display side Termination resistance...
  • Page 84 Temperature Controller MODBUS SIO Driver • 1:1 Connection External Device side Display side Terminal block Termination resistance Signal name Signal name Shield 120 Ω (1/2W) Termination T/R(B) resistance 120 Ω (1/2W) Display T/R(A) CA3-ADPCOM-01 CA3-ADPTRM-01 User-created cable • 1: n connection External Device side External Device side Shield...
  • Page 85 Temperature Controller MODBUS SIO Driver • 1:1 Connection Display side Terminal block Termination Signal name Shield External Device side resistance*1 Terminal block Signal name Termination T/R(B) resistance Display 120 Ω (1/2W) T/R(A) • 1:n Connection Display side Terminal block Signal name Termination Shield External Device...
  • Page 86 Temperature Controller MODBUS SIO Driver • 1:1 Connection External Device Display side D-Sub 9pin (plug) Terminal block Termination resistance Signal name Signal name Shield 120 Ω (1/2W) Termination T/R(B) LINE(+) resistance 120 Ω (1/2W) T/R(A) LINE(-) Display GND(SG) RS(RTS) Shell •...
  • Page 87 Temperature Controller MODBUS SIO Driver Cable Diagram 4 Display Cable Remarks (Connection Port) COM port conversion adapter by Pro-face CA3-ADPCOM-01 GP3000 (COM1) AGP-3302B (COM2) Terminal block conversion adapter by Pro-face GP-4*01TM (COM1) CA3-ADPTRM-01 (COM2) LT (COM1) User-created cable User-created cable Online adapter by Pro-face CA4-ADPONL-01 Cable length:...
  • Page 88 Temperature Controller MODBUS SIO Driver • 1:1 Connection External Device side COM.PORT1 Modular 6 Pin Display side Shield Signal name Signal name T(B) Display CA3-ADPCOM-01 T(A) R(B) R(A) CA3-ADPTRM-01 Shield User-created cable • 1: n connection External Device side External Device side COM.PORT2 COM.PORT1 COM.PORT1...
  • Page 89 Temperature Controller MODBUS SIO Driver • 1:1 Connection External Device side COM.PORT1 Display side Shield Modular 6 Pin Signal name Signal name T(B) Display CA4-ADPONL-01 T(A) R(B) R(A) CA3-ADPTRM-01 Shield User-created cable • 1:n Connection External Device side External Device side COM.PORT2 COM.PORT2 COM.PORT1...
  • Page 90 Temperature Controller MODBUS SIO Driver • 1:1 Connection External Device side Display side COM.PORT1 Terminal block Modular 6 Pin Shield Signal name Signal name T(B) Display T(A) R(B) R(A) Shield • 1:n Connection External Device side External Device COM.PORT2 COM.PORT1 COM.PORT2 Display side COM.PORT1...
  • Page 91 Temperature Controller MODBUS SIO Driver Cable Diagram 5 Display Cable Remarks (Connection Port) COM port conversion adapter by Pro-face CA3-ADPCOM-01 GP3000 (COM1) AGP-3302B (COM2) Terminal block conversion adapter by Pro-face GP-4*01TM (COM1) CA3-ADPTRM-01 (COM2) LT (COM1) User-created cable User-created cable Online adapter by Pro-face CA4-ADPONL-01 Terminal block conversion adapter by Pro-face...
  • Page 92 Temperature Controller MODBUS SIO Driver • 1:1 Connection Display side External Device side Signal name Shield COM.PORT1 Modular 6 Pin Display CA3-ADPCOM-01 Signal name T/R(B) T/R(A) CA3-ADPTRM-01 Shield User-created cable • 1: n connection Display side External Device side External Device side Signal name Shield COM.PORT1...
  • Page 93 Temperature Controller MODBUS SIO Driver • 1:1 Connection Display side D-Sub 9 Pin (socket) External Device side Signal name Shield COM.PORT1 Modular 6 Pin Signal name Display T/R(B) T/R(A) Shield Shell • 1:n Connection Display side D-Sub 9 Pin (socket) External Device side External Device Signal name...
  • Page 94 Temperature Controller MODBUS SIO Driver • 1:1 Connection Display side External Device side Signal name Shield COM.PORT1 Modular 6 Pin Display CA4-ADPONL-01 Signal name T/R(B) T/R(A) CA3-ADPTRM-01 Shield User-created cable • 1:n Connection Display side External Device side External Device side Shield Signal name COM.PORT2...
  • Page 95 Temperature Controller MODBUS SIO Driver • 1:1 Connection Display side D-Sub 9 Pin (plug) Signal name External Device side TERMRX Shield COM.PORT1 CA4-ADPONL-01 Modular 6 Pin Display Signal name T/R(B) T/R(A) Shield TERMTX Shell User-created cable • 1:n Connection Display side D-Sub 9 Pin (plug) Signal name External Device side...
  • Page 96 Temperature Controller MODBUS SIO Driver • 1:1 Connection External Device side COM.PORT1 Display side Modular 6 Pin Signal name Shield Signal name T/R(B) Display CA3-ADPCOM-01 T/R(A) Shield CA3-ADPTRM-01 User-created cable • 1: n connection External Device side External Device side COM.PORT2 COM.PORT1 COM.PORT2...
  • Page 97 Temperature Controller MODBUS SIO Driver • 1:1 Connection External Device side Display side COM.PORT1 D-Sub 9 Pin (socket) Modular 6 Pin Signal name Shield Signal name DATA+ T/R(B) DATA- T/R(A) Display Shield GND(SG) Shell • 1:n Connection External Device side External Device side Display side COM.PORT2...
  • Page 98 Temperature Controller MODBUS SIO Driver • 1:1 Connection Display side Terminal block External Device side Signal name Shield COM.PORT1 Modular 6 Pin Signal name Display T/R(B) T/R(A) Shield • 1:n Connection Display side Terminal block External Device side External Device Signal name Shield COM.PORT1...
  • Page 99 Temperature Controller MODBUS SIO Driver • 1:1 Connection External Device side Display side COM.PORT1 D-Sub 9pin (plug) Modular 6 Pin Signal name Shield Signal name LINE(+) T/R(B) LINE(-) T/R(A) Display Shield GND(SG) RS(RTS) Shell • 1:n Connection External Device side External Device side Display side COM.PORT2...
  • Page 100 Temperature Controller MODBUS SIO Driver Cable Diagram 6 Display Cable Remarks (Connection Port) GP3000 (COM1) GP-4*01TM (COM1) ST (COM1) User-created cable LT (COM1) Cable length: 15m or less PC/AT GP-4105 (COM1) User-created cable Only the COM port which can communicate by RS-232C can be used. IPC COM Port (page 7) Display side External Device side...
  • Page 101 Temperature Controller MODBUS SIO Driver Cable Diagram 7 Display Cable Remarks (Connection Port) COM port conversion adapter by Pro-face CA3-ADPCOM-01 GP3000 (COM1) AGP-3302B (COM2) Terminal block conversion adapter by Pro-face GP-4*01TM (COM1) CA3-ADPTRM-01 (COM2) LT (COM1) User-created cable User-created cable Online adapter by Pro-face CA4-ADPONL-01 Cable length:...
  • Page 102 Temperature Controller MODBUS SIO Driver • 1:1 Connection External Device side Terminal block Display side Shield Termination resistance Signal name Signal name 120 Ω (1/2W) Termination T(B) Display resistance CA3-ADPCOM-01 120 Ω (1/2W) T(A) Termination R(B) resistance 120 Ω (1/2W) R(A) CA3-ADPTRM-01 Termination...
  • Page 103 Temperature Controller MODBUS SIO Driver • 1:1 Connection External Device side Terminal block Display side Shield Termination resistance Signal name Signal name 120 Ω (1/2W) Termination T(B) Display resistance CA4-ADPONL-01 120 Ω (1/2W) T(A) Termination R(B) resistance 120 Ω (1/2W) R(A) CA3-ADPTRM-01 Termination...
  • Page 104 Temperature Controller MODBUS SIO Driver • 1:1 Connection External Device side Display side Terminal block Terminal block Shield Termination Signal name Signal name resistance*1 Termination Display T(B) resistance 120 Ω (1/2W) T(A) Termination R(B) resistance 120 Ω (1/2W) R(A) Termination resistance*1 •...
  • Page 105 Temperature Controller MODBUS SIO Driver Cable Diagram 8 Display Cable Remarks (Connection Port) COM port conversion adapter by Pro-face CA3-ADPCOM-01 GP3000 (COM1) AGP-3302B (COM2) Terminal block conversion adapter by Pro-face GP-4*01TM (COM1) CA3-ADPTRM-01 (COM2) LT (COM1) User-created cable User-created cable Online adapter by Pro-face CA4-ADPONL-01 Cable length:...
  • Page 106 Temperature Controller MODBUS SIO Driver • 1:1 Connection External Device side COM.PORT3 Display side Modular 6 Pin Shield Signal name Signal name T(B) Display CA3-ADPCOM-01 T(A) R(B) R(A) CA3-ADPTRM-01 Shield User-created cable • 1: n connection Broadcast Broadcast Display side Shield terminal terminal...
  • Page 107 Temperature Controller MODBUS SIO Driver • 1:1 Connection External Device side Display side COM.PORT3 D-Sub 9 Pin (socket) Shield Modular 6 Pin Signal name Signal name T(B) Display T(A) R(B) R(A) Shield Shell • 1:n Connection Display side Broadcast Broadcast D-Sub 9 Pin (socket) Shield terminal...
  • Page 108 Temperature Controller MODBUS SIO Driver • 1:1 Connection External Device side COM.PORT3 Display side Shield Modular 6 Pin Signal name Signal name T(B) Display CA4-ADPONL-01 T(A) R(B) R(A) CA3-ADPTRM-01 Shield User-created cable • 1:n Connection Broadcast Broadcast Display side Shield terminal Shield terminal...
  • Page 109 Temperature Controller MODBUS SIO Driver • 1:1 Connection Display side External Device side D-Sub 9 Pin (plug) COM.PORT3 Signal name Shield Modular 6 Pin TERMRX Signal name CA4-ADPONL-01 T(B) Display T(A) R(B) R(A) TERMTX Shield Shell User-created cable • 1:n Connection Display side D-Sub 9 Pin (plug) Broadcast...
  • Page 110 Temperature Controller MODBUS SIO Driver • 1:1 Connection External Device side Display side COM.PORT3 Terminal block Shield Modular 6 Pin Signal name Signal name T(B) Display T(A) R(B) R(A) Shield • 1:n Connection Display side Broadcast Broadcast Terminal block Shield terminal Shield terminal...
  • Page 111 Temperature Controller MODBUS SIO Driver Cable Diagram 9 Display Cable Remarks (Connection Port) COM port conversion adapter by Pro-face CA3-ADPCOM-01 GP3000 (COM1) AGP-3302B (COM2) Terminal block conversion adapter by Pro-face GP-4*01TM (COM1) CA3-ADPTRM-01 (COM2) LT (COM1) User-created cable User-created cable Online adapter by Pro-face CA4-ADPONL-01 Terminal block conversion adapter by Pro-face...
  • Page 112 Temperature Controller MODBUS SIO Driver • 1:1 Connection Display side External Device side Shield Signal name COM.PORT3 Modular 6 Pin Display CA3-ADPCOM-01 Signal name T/R(B) T/R(A) CA3-ADPTRM-01 Shield User-created cable • 1: n connection Display side Signal name Shield Broadcast Broadcast terminal Shield...
  • Page 113 Temperature Controller MODBUS SIO Driver • 1:1 Connection Display side D-Sub 9 Pin (socket) External Device side Signal name Shield COM.PORT3 Modular 6 Pin Display Signal name T/R(B) T/R(A) Shield Shell • 1:n Connection Display side D-Sub 9 Pin (socket) Signal name Shield Broadcast...
  • Page 114 Temperature Controller MODBUS SIO Driver • 1:1 Connection Display side External Device side Signal name Shield COM.PORT3 Modular 6 Pin Display CA4-ADPONL-01 Signal name T/R(B) T/R(A) CA3-ADPTRM-01 Shield User-created cable • 1:n Connection Display side Signal name Shield Broadcast Broadcast terminal Shield terminal...
  • Page 115 Temperature Controller MODBUS SIO Driver • 1:1 Connection Display side D-Sub 9 Pin (plug) Signal name External Device side TERMRX Shield COM.PORT3 CA4-ADPONL-01 Modular 6 Pin Display Signal name T/R(B) T/R(A) Shield TERMTX Shell User-created cable • 1:n Connection Display side D-Sub 9 Pin (plug) Signal name TERMRX...
  • Page 116 Temperature Controller MODBUS SIO Driver • 1:1 Connection External Device side COM.PORT3 Display side Modular 6 Pin Shield Signal name Signal name T/R(B) Display CA3-ADPCOM-01 T/R(A) Shield CA3-ADPTRM-01 User-created cable • 1: n connection Broadcast Broadcast Display side terminal Shield terminal Signal name Signal name...
  • Page 117 Temperature Controller MODBUS SIO Driver • 1:1 Connection External Device side Display side COM.PORT3 D-Sub 9 Pin (socket) Modular 6 Pin Signal name Signal name Shield DATA+ T/R(B) Display DATA- T/R(A) Shield GND(SG) Shell • 1:n Connection Display side Broadcast Broadcast D-Sub 9 Pin (socket) Shield...
  • Page 118 Temperature Controller MODBUS SIO Driver • 1:1 Connection Display side Terminal block External Device side Signal name Shield COM.PORT3 Modular 6 Pin Display Signal name T/R(B) T/R(A) Shield • 1:n Connection Display side Terminal block Signal name Shield Broadcast Broadcast Shield terminal terminal...
  • Page 119 Temperature Controller MODBUS SIO Driver • 1:1 Connection External Device side Display side COM.PORT3 D-Sub 9pin (plug) Modular 6 Pin Signal name Signal name Shield LINE(+) T/R(B) Display LINE(-) T/R(A) Shield GND(SG) RS(RTS) Shell • 1:n Connection Display side Broadcast Broadcast D-Sub 9pin (plug) Shield...
  • Page 120 Temperature Controller MODBUS SIO Driver Cable Diagram 10 Display Cable Remarks (Connection Port) COM port conversion adapter by Pro-face CA3-ADPCOM-01 GP3000 (COM1) AGP-3302B (COM2) Terminal block conversion adapter by Pro-face GP-4*01TM (COM1) CA3-ADPTRM-01 (COM2) LT (COM1) User-created cable User-created cable Online adapter by Pro-face CA4-ADPONL-01 Terminal block conversion adapter by Pro-face...
  • Page 121 Temperature Controller MODBUS SIO Driver 10A) • 1:1 Connection Display side Signal name Shield External Drive side Terminal block Termination Display resistance CA3-ADPCOM-01 Signal name 120 Ω (1/2W) T/R(B) T/R(A) CA3-ADPTRM-01 User-created cable • 1:n Connection (When connecting with the internal communication line) Display side Signal name Shield...
  • Page 122 Temperature Controller MODBUS SIO Driver 10B) • 1:1 Connection Display side D-Sub 9 Pin (socket) Termination resistance Signal name Shield 120 Ω (1/2W) External Device side Terminal block Termination resistance Signal name 120 Ω (1/2W) Display T/R(B) T/R(A) Shell • 1:n Connection (When connecting with the internal communication line) Display side D-Sub 9 Pin (socket)
  • Page 123 Temperature Controller MODBUS SIO Driver 10C) • 1:1 Connection Display side Signal name Shield External Device side Terminal block Termination Display resistance CA4-ADPONL-01 Signal name 120 Ω (1/2W) T/R(B) T/R(A) CA3-ADPTRM-01 User-created cable • 1:n Connection (When connecting with the internal communication line) Display side Signal name Shield...
  • Page 124 Temperature Controller MODBUS SIO Driver 10D) • 1:1 Connection Display side D-Sub 9 Pin (plug) Signal name TERMRX Shield External Device side CA4-ADPONL-01 Terminal block Termination Display resistance Signal name 120 Ω (1/2W) T/R(B) T/R(A) TERMTX Shell User-created cable • 1:n Connection (When connecting with the internal communication line) Display side D-Sub 9 Pin (plug)
  • Page 125 Temperature Controller MODBUS SIO Driver 10E) • 1:1 Connection Display side Shield External Device side Terminal block Signal name Termination resistance Signal name 120 Ω (1/2W) T/R(B) Display CA3-ADPCOM-01 T/R(A) CA3-ADPTRM-01 User-created cable • 1:n Connection (When connecting with the internal communication line) Display side Shield External Device side...
  • Page 126 Temperature Controller MODBUS SIO Driver 10F) • 1:1 Connection Display side External Device side D-Sub 9 Pin (socket) Terminal block Termination Termination Shield resistance resistance Signal name Signal name 120 Ω (1/2W) 120 Ω (1/2W) DATA+ T/R(B) DATA - T/R(A) Display Shell •...
  • Page 127 Temperature Controller MODBUS SIO Driver 10G) • 1:1 Connection Display side Terminal block Signal name Termination Shield External Device side resistance*1 Terminal block Termination resistance Signal name 120 Ω (1/2W) Display T/R(B) T/R(A) • 1:n Connection (When connecting with the internal communication line) Display side Terminal block Termination...
  • Page 128 Temperature Controller MODBUS SIO Driver 10H) • 1:1 Connection Display side External Device side D-Sub 9pin (plug) Terminal block Termination Shield Termination resistance Signal name resistance Signal name 120 Ω (1/2W) 120 Ω (1/2W) T/R(B) LINE(+) T/R(A) LINE(-) Display GND(SG) RS(RTS) Shell •...
  • Page 129 Only the COM port which can communicate by RS-422/485 (4wire) can be used. IPC COM Port (page 7) All GP3000 models except GP-3200 and AGP-3302B To use multiple External Devices, utilize the W-BF-02 connector cable from RKC Instrument Inc. GP-Pro EX Device/PLC Connection Manual...
  • Page 130 Temperature Controller MODBUS SIO Driver 11A) • 1:1 Connection External Device side Terminal block COM.PORT1 Display side or COM.PORT3 Shield modular connector Signal name Display External Device Signal name CA3-ADPCOM-01 T(B) Connect the terminating T(A) resistor connector CA3-ADPTRM-01 W-BW-02 for Z-COM R(B) to COM.PORT2 R(A)
  • Page 131 Temperature Controller MODBUS SIO Driver 11B) • 1:1 Connection External Device side Terminal block COM.PORT1 Display side or COM.PORT3 Shield D-Sub 9 Pin (socket) modular connector Termination External resistance Device Signal name Signal name 120 Ω (1/2W) T(B) Termination Connect the terminating resistance T(A) 120 Ω...
  • Page 132 Temperature Controller MODBUS SIO Driver 11C) • 1:1 Connection External Device side Terminal block COM.PORT1 Display side or COM.PORT3 Shield Signal name modular connector External Display Device Signal name CA4-ADPONL-01 T(B) Connect the terminating T(A) resistor connector CA3-ADPTRM-01 R(B) W-BW-02 for Z-COM Termination to COM.PORT2 R(A)
  • Page 133 Temperature Controller MODBUS SIO Driver 11D) • 1:1 Connection External Device side Terminal block Display side COM.PORT1 D-Sub 9 Pin (plug) or COM.PORT3 Shield modular connector Signal name External Device TERMRX Signal name CA4-ADPONL-01 T(B) Connect the terminating Display T(A) resistor connector W-BW-02 for Z-COM R(B)
  • Page 134 Temperature Controller MODBUS SIO Driver 11E) • 1:1 Connection External Device side Terminal block COM.PORT1 Display side or COM.PORT3 Shield Terminal block modular connector External Device Signal name Signal name Termination resistance*1 T(B) Connect the terminating T(A) Termination resistor connector resistance*1 W-BW-02 for Z-COM R(B)
  • Page 135 Terminal block conversion adapter by Pro-face CA3-ADPTRM-01 GP3000 (COM1) AGP-3302B (COM2) User-created cable GP-4*01TM (COM1) (COM2) Connector cable from RKC Instrument Inc. LT (COM1) W-BF-02 User-created cable Connector cable from RKC Instrument Inc. W-BF-02 Online adapter by Pro-face CA4-ADPONL-01 Terminal block conversion adapter by Pro-face...
  • Page 136 All GP3000 models except GP-3200 and AGP-3302B Only the COM port which can communicate by RS-422/485 (2wire) can be used. IPC COM Port (page 7) To use multiple External Devices, utilize the W-BF-02 connector cable from RKC Instrument Inc. 12A) •...
  • Page 137 Temperature Controller MODBUS SIO Driver 12B) • 1:1 Connection External Device side Display side Terminal block D-Sub 9 Pin (socket) Termination COM.PORT1 resistance Signal name External Shield 120 Ω (1/2W) or COM.PORT3 Device modular connector Connect the terminating Signal name resistor connector Display T/R(B)
  • Page 138 Temperature Controller MODBUS SIO Driver 12C) • 1:1 Connection External Device side Display side Terminal block Signal name COM.PORT1 Shield External or COM.PORT3 Device modular connector Display CA4-ADPONL-01 Connect the terminating Signal name resistor connector T/R(B) W-BW-01 for Z-COM T/R(A) to COM.PORT2 CA3-ADPTRM-01 or COM.PORT4.
  • Page 139 Temperature Controller MODBUS SIO Driver 12D) • 1:1 Connection Display side External Device side D-Sub 9 Pin (plug) Terminal block Signal name COM.PORT1 External TERMRX Shield or COM.PORT3 CA4-ADPONL-01 Device modular connector Display Connect the terminating Signal name resistor connector T/R(B) W-BW-01 for Z-COM T/R(A)
  • Page 140 Temperature Controller MODBUS SIO Driver 12E) • 1:1 Connection External Device side Terminal block COM.PORT1 Display side Shield External or COM.PORT3 Device Signal name modular connector Signal name Connect the terminating Display resistor connector T/R(B) CA3-ADPCOM-01 W-BW-01 for Z-COM T/R(A) to COM.PORT2 or COM.PORT4.
  • Page 141 Temperature Controller MODBUS SIO Driver 12F) • 1:1 Connection External Device side Terminal block COM.PORT1 External Display side or COM.PORT3 Device D-Sub 9 Pin (socket) Shield modular connector Termination resistance Signal name Connect the terminating 120 Ω (1/2W) Signal name DATA+ resistor connector T/R(B)
  • Page 142 Temperature Controller MODBUS SIO Driver 12G) • 1:1 Connection External Device side Display side Terminal block Terminal block COM.PORT1 Termination Signal name External Shield or COM.PORT3 resistance*1 Device modular connector Connect the terminating Signal name resistor connector Display T/R(B) W-BW-01 for Z-COM T/R(A) to COM.PORT2 or COM.PORT4.
  • Page 143 Temperature Controller MODBUS SIO Driver 12H) • 1:1 Connection External Device side Terminal block COM.PORT1 Display side External or COM.PORT3 D-Sub 9pin (plug) Device modular connector Shield Termination resistance Signal name Connect the terminating 120 Ω (1/2W) Signal name resistor connector LINE(+) T/R(B) W-BW-01 for Z-COM...

  • Page 144: Supported Device

    Temperature Controller MODBUS SIO Driver Supported Device Range of supported device address is shown in the table below. Please note that the actually supported range of the devices varies depending on the External Device to be used. Please check the actual range in the manual of your External Device.
  • Page 145 Temperature Controller MODBUS SIO Driver CB Series This address can be specified as system data area. Device Bit Address Word Address Remarks bits Holding Register 0000.0-001C.F 0000-001C When you write the bit address, the Display reads the word address corresponding to that of the External Device first.
  • Page 146 Temperature Controller MODBUS SIO Driver • You can set only Read Area Size for the system data area available to use in the Temperature Controller. Please refer to the GP-Pro EX Reference Manual for reading area size. GP-Pro EX Reference Manual "LS Area (Direct Access Method Area)" •...
  • Page 147 Temperature Controller MODBUS SIO Driver MA900/901 Series This address can be specified as system data area. Device Bit Address Word Address Remarks bits Holding Register 0000.0-14A0.F 0000-14A0 When you write the bit address, the Display reads the word address corresponding to that of the External Device first.
  • Page 148 Temperature Controller MODBUS SIO Driver • You can set only Read Area Size for the system data area available to use in the Temperature Controller. Please refer to the GP-Pro EX Reference Manual for reading area size. GP-Pro EX Reference Manual "LS Area (Direct Access Method Area)" •...
  • Page 149 Temperature Controller MODBUS SIO Driver SA100 Series This address can be specified as system data area. Device Bit Address Word Address Remarks bits Holding Register 0000.0-0021.F 0000-0021 When you write the bit address, the Display reads the word address corresponding to that of the External Device first.
  • Page 150 Temperature Controller MODBUS SIO Driver • You can set only Read Area Size for the system data area available to use in the Temperature Controller. Please refer to the GP-Pro EX Reference Manual for reading area size. GP-Pro EX Reference Manual "LS Area (Direct Access Method Area)" •...
  • Page 151 Temperature Controller MODBUS SIO Driver 6.10 SR Mini HG(H-PCP-J) Series This address can be specified as system data area. Device Bit Address Word Address Remarks bits Holding Register 0000.0-1DEE.F 0000-1DEE When you write the bit address, the Display reads the word address corresponding to that of the External Device first.
  • Page 152 Temperature Controller MODBUS SIO Driver 6.11 SRZ (Z-TIO) / SRZ (Z-DIO) Series This address can be specified as system data area. Device Bit Address Word Address Remarks bits Holding Register 0000.0-150F.F 0000-150F When you write the bit address, the Display reads the word address corresponding to that of the External Device first.
  • Page 153 Temperature Controller MODBUS SIO Driver 6.12 SRZ (Z-CT) Series This address can be specified as system data area. Device Bit Address Word Address Remarks bits Holding Register 0000.0-01F1.F 0000-01F1 When you write the bit address, the Display reads the word address corresponding to that of the External Device first.
  • Page 154 Temperature Controller MODBUS SIO Driver 6.13 SRZ (Z-COM) Series This address can be specified as system data area. Device Bit Address Word Address Remarks bits Holding Register 0000.0-801B.F 0000-801B When you write the bit address, the Display reads the word address corresponding to that of the External Device first.

  • Page 155: Device Code And Address Code

    Temperature Controller MODBUS SIO Driver Device Code and Address Code Use device code and address code when you select "Device Type & Address" for the address type in data displays. CB Series Device Code Device Device Name Address Code (HEX)
  • Page 156 Temperature Controller MODBUS SIO Driver SA200 Series Device Code Device Device Name Address Code (HEX) Holding Register 0080 Same as Word Address SR Mini Series Device Code Device Device Name Address Code (HEX) Holding Register 0080 Same as Word Address 7.10 SR Mini HG Series Device Code...

  • Page 157: Error Messages

    Temperature Controller MODBUS SIO Driver Error Messages Error messages are displayed on the screen of the Display as follows: "No.:Device Name:Error Message(Error Occurrence Area)". Each description is shown below. Item Description Error No. Name of the External Device where error occurs. Device name is a title of the External Device Name Device set with GP-Pro EX.(Initial value[PLC1]) Error Message...
  • Page 158 Temperature Controller MODBUS SIO Driver GP-Pro EX Device/PLC Connection Manual...

This manual is also suitable for:

Fb400 seriesFb900 seriesHa400 seriesHa900 seriesMa900 seriesMa901 series ... Show all
