- Page 1 Owners Manual 5DA52 Total fan weight KGS. LBS. WARNING : Read and follow these instructions carefully and be mindful of all warnings shown throughout.
- Page 2 READ AND SAVE THESE INSTRUCTIONS WARNING : TO REDUCE THE RISK OF FIRE, ELECTRICAL SHOCK, OR INJURY TO PERSONS, PLEASE OBSERVE THE FOLLOWING : 1 . To ensure the success of the installation, be sure to read the instructions and review the diagrams thoroughly before beginning.
- Page 3 1.Unpack and inspect fan carefully to be certain all contents are included. Hardware bag Spring Washer 2 pcs Lock Washer 2 pcs Wood Screw 2 pcs Mounting bracket Downrod Blade Balance Kit 1 pc Blade screw 21pcs Paper washer 21pcs Yoke cover Motor screw 11pcs...
- Page 4 5a-1. Yoke & Downrod Assembly Wires Canopy Downrod Downrod Yoke cover Cross Pin Cotter Pin Cotter Pin Cross Pin Yoke Downrod Set Screw Yoke Insert the cross pin through yoke & downrod and Feed motor lead wires through yoke cover , secure with cotter pin.
-
Page 5: Canopy Installation
6. Make wire connection Follow diagram below and make sure that all exposed wires are secured inside wire nuts. Note : Wires from house may vary in color and may not include ground wire ( green ). After wiring is completed, gently push wires into junction box with nuts pointing upward. From House From Fan White... - Page 6 9. Blades assembly to motor Motor stopper 1.Remove of 3 pcs motor stopper 2.Attach blade assembly to motor and fasten by motor screw from hardware bag. NOTE: Do not bend blade holder to prevent wobble. Blade assembly 10. Assembly switch housing cover & knob Attach switch housing cover to fan by 3pcs of switch housing Switch housing...
