Owner's Manual
Starfire
These instructions contain 5 pages:
Page 1: Foreword
Page 2: Unpack and inspect parts contained, and pre-installation notes
Page 3: Canopy and Blade installation, Optional Light Pre-Assembly
Page 4: Hanging system installation and Wiring connections
Page 5: Light Cover and Non-Light Cover installation and Remote setting
Toll Free 1-855-676-7247
WARNING: Read and follow these instructions carefully and be mindful of all warnings shown throughout.
Model No:
56DFH-L
HS-1289-C
Cover for non-light option
Net Weight
5.04 KGS
11.1 LBS
Advertisement
Table of Contents
Related Manuals for TroposAir Starfire 56DFH-L
Summary of Contents for TroposAir Starfire 56DFH-L
- Page 1 Owner’s Manual Starfire Model No: 56DFH-L HS-1289-C Cover for non-light option These instructions contain 5 pages: Page 1: Foreword Page 2: Unpack and inspect parts contained, and pre-installation notes Page 3: Canopy and Blade installation, Optional Light Pre-Assembly Page 4: Hanging system installation and Wiring connections Page 5: Light Cover and Non-Light Cover installation and Remote setting Net Weight 5.04 KGS...
- Page 2 READ AND SAVE THESE INSTRUCTIONS WARNING : TO REDUCE THE RISK OF FIRE, ELECTRICAL SHOCK, OR INJURY TO PERSONS, PLEASE OBSERVE THE FOLLOWING: To ensure success of installation, be sure read these instructions and review the diagrams thoroughly before beginning. To avoid possible electric shock, be sure electricity is turned off at the main power box before wiring.
- Page 3 Unpack and inspect fan carefully to be certain all contents are included. Mounting Bracket Downrod Assembly Blade x4 Canopy Yoke Cover Hardware Bag For Mounting Bracket: Flat Washer x2 Fan Wires Star Washer x2 Spring Washer x2 Machine Screw x2 Motor Wood Screw x2 Assembly...
- Page 4 1. HANGING SYSTEM INSTALLATION 1A. Installing mounting bracket to ceiling outlet box Install mounting bracket to outlet box in ceiling Outlet Box by using screws included with the outlet box and washers from the hardware bag. Mounting Bracket 1B. Installing Downrod and Yoke Place motor right side up onto styrofoam packing Remove cross pin, washer and cotter pin from downrod.
-
Page 5: Installing The Canopy
3. CANOPY INSTALLATION 3. Installing the canopy Note: Two screws are pre-installed on mounting bracket for canopy installation. You will need to remove one and loosen the other slightly. Canopy Push up canopy until the screw still in the mounting bracket is engaged with the large end of the keyhole on canopy. - Page 6 6A. OPTIONAL NO LIGHT DIS-ASSEMBLY If you are not installing the light, The LED Light Pan must be removed 5. Removing the LED Light Pan Remove the three screws holding the clear cover to the LED array. Motor Unplug the wire connector from the LED array. Plate Remove the three screws holding the Light Pan to the motor plate.
