Owner's Manual
Enterprise III
These instructions contain 5 pages:
Page 1: Foreword
Page 2: Unpack and inspect parts contained, and pre-installation notes
Page 3: Hanging system installation and Remote setting
Page 4: Wire connection and Canopy installation
Page 5: Blade and Light/Cover installation
Toll Free 1-855-676-7247
WARNING: Read and follow these instructions carefully and be mindful of all warnings shown throughout.
Model No: 50NDE-L
Net Weight
7.72 KGS
17.0 LBS
Advertisement
Table of Contents
Related Manuals for TroposAir Enterprise III
Summary of Contents for TroposAir Enterprise III
- Page 1 Owner’s Manual Enterprise III Model No: 50NDE-L These instructions contain 5 pages: Page 1: Foreword Page 2: Unpack and inspect parts contained, and pre-installation notes Page 3: Hanging system installation and Remote setting Page 4: Wire connection and Canopy installation...
- Page 2 READ AND SAVE THESE INSTRUCTIONS WARNING : TO REDUCE THE RISK OF FIRE, ELECTRICAL SHOCK, OR INJURY TO PERSONS, PLEASE OBSERVE THE FOLLOWING: To ensure success of installation, be sure read these instructions and review the diagrams thoroughly before beginning. To avoid possible electric shock, be sure electricity is turned off at the main power box before wiring.
- Page 3 Unpack and inspect fan carefully to be certain all contents are included. Hardware Bag For Mounting Bracket: Mounting Flat Washer x2 Bracket Star Washer x2 Spring Washer x2 Machine Screw x2 Downrod Assembly Wood Screw x2 For Wire Connection Wire Nut x3 Canopy For Blade Installation Trim...
- Page 4 1. HANGING SYSTEM INSTALLATION 1A. Installing mounting bracket to ceiling outlet box Install mounting bracket to outlet box in ceiling Outlet Box by using screws included with the outlet box and washers from the hardware bag. Mounting Bracket 1B. Installing Downrod and Yoke Remove cross pin washer and cotter pin from downrod.
- Page 5 4. BLADE INSTALLATION 4. Installing the blades Countersink Screws (2) Align three smaller holes in blade with the three posts on blade arm and secure with blade screws and washers. Blade Repeat for remaining blades. Screws & Position trim arch as shown and secure to motor and Washers to blade arm using the countersink screws.
