EVAL-ADAS3022EDZ User Guide
PRODUCTS ON THIS EVALUATION BOARD
BILL OF MATERIALS
Table 8.
Qty
Reference Description
5
U1 to U3, U8, U12
2
U10, U11
1
U20
1
U4
1
A1
1
A2
1
U6
1
U5
1
Y3
22
C108, C111 to C131
2
C45, C89
1
C107
6
C17, C20, C24, C25, C36,
C88
6
C66 to C68, C79 to C81
11
C38,C65, C70, C71, C72,
C73, C75, C76, C77, C78,
C92
7
C8, C29 to C31, C86, C109,
C110
11
C43,C44, C46, C47, C49,
C50, C57, C59, C60, C62,
C63
9
C1, C3, C4, C6, C10, C51,
C53, C55, C56
8
C2, C5, C48, C52, C54,
C58, C61, C64
15
C7, C9, C18, C19, C21,
C22, C26 to C28, C32 to
C34, C37, C85, C87
10
C11 to C16, C23, C35, C69,
C74
2
C84, C90
7
C39 to C42, C91, C93, C94
1
R94
4
R32, R72, R73, R103
6
R2, R71, R125, R126, R136,
R151
6
R30, R31, R59, R137, R137,
R151
9
R60 to R68
18
R74 to R78, R121, R122,
R128, R130, R132, R134,
R138 to R144
2
R125, R126
2
R13, R55
Part Description
Value
IC-ADI LDO
–
IC-ADI LDO
–
IC-ADI OPAMP
–
IC-ADI OPAMP
–
IC-ADI REFERENCE
–
IC-ADI REFERENCE
–
IC-CYCLONE II
–
IC SERIAL CONFIG
–
IC CRYSTAL OSC
100 MHZ
CAP X7R 0402
0.1 µF
CAP X7R 0508
0.1 µF
CAP NP0 0603
100 pF
CAP X8R 0603
0.1 µF
CAP X7R 0603
CAP X7R 0805
0.1 µF
CAP C0G 0805
1000 pF
CAP NPO 0805
2700 pF
CAP NPO 0805
2700 pF
CAP NPO 0805
5600 pF
CAP X5R 0805
2.2 µF
CAP X5R 0805
10 µF
CAP TANT
10 µF
CAP 0805
RES 0402
0
RES 0603
–
RES 0603
–
RES 0603
0
RES 0603, 5%
50
RES 0603, 5%
10 K
RES 0603, 5%
15 K
RES 0603, 1%
140 K
Rev. A | Page 27 of 32
Manufacturer
Part Number
Analog Devices
ADP3334ACPZ
Analog Devices
ADP1715ARMZ
Analog Devices
AD8032ARZ
Analog Devices
ADA4841-2YRZ
Analog Devices
ADR434ARMZ
Analog Devices
ADR381ARTZ
Altera Devices
EP2C5F256C7N
Altera Devices
EPCS4SI8N
C-MAC
SPXO009437-CFPS-73
Murata
GRM155R71C104KA88D
TDK
C1220X7R1E104K
Phycomp
2238 867 15101
Murata
GRM188R7E104KA01D
Murata
GRM21BR71H104KA01L
Murata
GRM2165C2A102JA01D
Murata
GRM2165C1H272JA01D
Murata
GRM2165C1H272JA01D
Murata
GRM2195C1H562JA01D
Murata
GRM21BR71E225KA73L
Murata
GRM21BR61C106KE15L
AVX
TAJA106K010RNJ
Murata
–
Panasonic-ECG
ERJ-2GE0R00X
Panasonic-ECG
–
Panasonic-ECG
–
Panasonic-ECG
ERJ-3GEY0R00V
Panasonic-ECG
ERJ-3EKF49R9V
Panasonic-ECG
ERJ-3EKF1002V
Yageo
RC0603FR-0715KL
Panasonic-ECG
UG-484
Instructions
DNI
DNI
DNI
DNI
DNI
DNI
DNI
DNI
