UG-484
Qty Reference Description
14
R1, R24 to R26, R29, R80
to R82, R85, R86, R95, R97,
R99, R100
25 R7 to R9, R19 to R23, R41
to R49, R69, R70, R90 to
R93, R96, R101
2 R57, R58
9 R34 to R40, R50, R55
1 R27
9 R33, R52 to R54, R79, R83,
R84, R87, R88
1 R28
2 R89, R145
2 R3, R5
2 R4, R6
6 R10 to R12, R98, R102,
R135
1 R16
2 R14, R56
1 R18
1 R17
1 R15
2 CR1,CR2
3 P5, P7, P31
1 P2
1 P1
1 P3
1 P4
6 GND(S)
2 +15 V, MCLK
4 REF, +5 V A, +5 V D, REFIN
2 −15 V, −5 VA
26 PD, CNV, CSB, DIN,
SCK, SDO, VIO,
AVDD, BUSY, DVDD,
VDDH, VSSH,
AUX+I, AUX−I,
COM_I, IN0_I−IN7_I,
RESET, VDRV+,
VDRV−
Part Description Value
RES 0805 –
RES 0805 0
RES 0805, 1% 22
RES 0805, 1% 90.9
RES 0805, 1% 365
RES 0805, 1% 499
RES 0805, 1% 590
RES 0805, 1% 604
RES 0805, 5% 1 K
RES 0805, 5% 2 K
RES 0805, 5% 10 K
RES 0805, 1% 64.9 K
RES 0805, 1% 78.7 K
RES 0805, 1% 95.3 K
RES 0805, 1% 107 K
RES 0805, 1% 210 K
LED Green
CONN-3 PIN MALE Breakaway
CONN-10 PIN MALE RA, shroud
CONN-26 PIN MALE Shroud
CONN-40 PIN MALE RA, Shroud
CONN-96 PIN MALE RA, DIN
Test point Black
Test point Yellow
Test point Red
Test point White
Test point Blue
Rev. A | Page 28 of 32
EVAL-ADAS3022EDZ User Guide
Manufacturer Part Number
Panasonic-ECG –
Panasonic-ECG ERJ-6GEY0R00V
Panasonic-ECG ERJ-6ENF22R0V
Panasonic-ECG ERJ-6ENF90R9V
Panasonic-ECG ERJ-6ENF3652V
Panasonic-ECG ERJ-6ENF4990V
Panasonic-ECG ERJ-6ENF5902V
Panasonic-ECG ERJ-6ENF6040V
Panasonic-ECG ERJ-6ENF1001V
Panasonic-ECG ERJ-6ENF2001V
Panasonic-ECG ERJ-6ENF1002V
Panasonic-ECG ERJ-6ENF6492V
Panasonic-ECG ERJ-6ENF7872V
Panasonic-ECG ERJ-6ENF6042V
Yageo RC0805FR-07300KL
Panasonic-ECG ERJ-6ENF2103V
Chicago MINI LAMP CMD28-21VGCTR8T1
Samtec TSW-103-08-G-S
3M 2510-5002UB
3M 30326-6002HB
3M 2540-6002UB
ERNI 533402
Components Corp TP-104-01-00
Components Corp TP-104-01-04
Components Corp TP-104-01-02
Components Corp TP-104-01-09
Components Corp TP-104-01-06
Instructions
DNI
