Easy to Use AD4000 Series 16-/18-/20-Bit Precision SAR ADCs User Guide

PRODUCTS ON THIS EVALUATION BOARD

AD4000/AD4001/AD4002/AD4003/AD4020
Table 5. Bill of Materials
Name Part Description
U1
16-/18-bit, 2 MSPS or 20-bit, 1.8 MSPS
precision SAR ADC in 10-lead MSOP
U2 Ultralow power, low distortion ADC
driver, 4 nV/√Hz
U3 High voltage, 1.2 MHz/600 kHz,
800 mA, low quiescent current
buck regulator
U4 Linear regulator, 3.3 V, ultralow
noise, complementary metal–oxide
semiconductor (CMOS)
U6 Ultralow noise, high accuracy
voltage reference
U7 CMOS, switched capacitor voltage
converter
U8 IC EEPROM, 2 kb, 400 kHz, 8-lead
SOIC
U12, U14 (only for Low noise, high speed amplifiers
AD4001/AD4002/
AD4003/AD4020)
U12, U14 (only for Low noise, high speed amplifiers
AD4000)
U16, U18 Low noise, high speed amplifiers
U17 Linear regulator, 3.3 V, ultralow
noise, CMOS
U19 Linear regulator, 1.8 V, ultralow
noise, CMOS
U20 Ultralow power step-down regulator
U21 –28 V, −200 mA, low noise, linear
regulator
U22 Micropower, high accuracy, 5 V
voltage reference
C1, C2, C5, C9, C61 10 µF, 20 V tantalum capacitors
C3, C4, C16, C17, C21, 2.2 µF, X7R, 16 V, 0805 capacitors,
C26 MLCC
C6 4.7 µF, 16 V, X7R, 0805 ceramic
capacitor
10 µF, 16 V, 0805 capacitors
C7, C10, C12, C18, C40,
C68, C73, C74, C75,
C76, C77
C8, C57, C64, C69, C71 1 µF, X7R, 50 V, 0805 capacitors
C14, C15 100 nF, X7R, 25 V, 0805 capacitors
0.1 µF, X7R, 50 V ceramic capacitors
C24, C30, C37, C41,
C42, C44, C45, C48,
C54, C60, C66, C67,
C70
C35, C52 180 pF, 50 V, 0603, C0G/NP0
capacitors
C11, C13, C19, C20, SMD capacitors
C25, C29, C32, C36,
C38, C39, C43, C46,
C47, C49, C50, C51,
C55, C63, C72
EVALUATION BOARD BILL OF MATERIALS
Manufacturer Part Number
Analog Devices See Table 6
Analog Devices ADA4940-1
Analog Devices ADP2370
Analog Devices ADP7118
Analog Devices ADR4550
Analog Devices ADM660
ST M24C02-WMN6TP
Analog Devices ADA4807-1
Analog Devices ADA4805-1
Analog Devices ADA4807-1
Analog Devices ADP7118
Analog Devices ADP7118
Analog Devices ADP5300
Analog Devices ADP7182
Analog Devices ADR3450
AVX TAJB106K020RNJ
Murata GRM21BR71C225KA12L
Taiyo Yuden EMK212B7475KG-T
Murata GRM219R61C106KA73D
Murata GRM21BR71H105KA12L
Murata LLL216R71E104MA01L
Murata GRM188R71H104KA93D
YAGEO CC0603JRNPO9BN181
(Phycomp)
Not applicable Not applicable
Rev. E | Page 23 of 25
UG-1042
Stock Code
See Table 6
Do not place
ADP2370ACPZ-5.0-R7
ADP7118AUJZ-3.3-R7
ADR4550BRZ
ADM660ARZ
Digi-Key 497-8552-1-ND
ADA4807-1ARJZ
ADA4805-1ARJZ
ADA4807-1ARJZ
ADP7118AUJZ-3.3-R7
ADP7118AUJZ-1.8-R7
ADP5300ACPZ-1-R7
ADP7182AUJ-2.5-R7
ADR3450ARJZ-R2
FEC 197427
FEC 1828829
FEC 1853520
FEC 1845747
FEC 1735541
FEC 1294646
FEC 8820023
FEC 3019494
Do not place
