TIME DOMAIN TAB

Figure 28 illustrates the Time Domain tab. The
output is twos complement output; however, the software
outputs the results in straight binary.
2
ADAS3022
1
Figure 28. Time Domain Tab
Rev. A | Page 15 of 32
Note that Label 1 shows the Waveform Analysis that reports
the amplitude recorded from the captured signal in addition to
the frequency of the signal tone, and Label 2 shows that Y-axis
units can be displayed in volts or code (LSB).
