Fisher FIELDVUE DVC6200 Instruction Manual page 2

Field Communicator Fast-Key Sequence and Menu Trees
Instrument Level HC, AD, PD, and ODV
Function/Variable
Actuator Style
Alert Conditions
Alert Record Full Enable
Alert Record Not Empty Alert
Enable
Analog Input
Analog Input Calibration
Analog Input Range Hi
Analog Input Range Lo
Analog Input Units
Auto Calibration
Autocalibration in Progress Enable
Auxiliary Input
Auxiliary Terminal Alert Enable
Auxiliary Terminal Mode
Burst Command
Burst Enable
Calibration in Progress Enab
Calibration Location
Clear Record
Command 3 (Trending) Pressure
Control Mode
Critical NVM Shutdown
Cycle Count
Cycle Count Alert Enable
Cycle Count Alert Point
Date
Dead Band (Cycle Count / Travel
Accum)
Define Custom Characteristic
Descriptor
Device Description Information
Device ID
Device Revision
Diagnostic Data Available Enable
Diagnostic in Progress Enable
Display Record
Drive Current Shutdown
Drive Signal
Drive Signal Alert Enable
NOTE: Italicized Fast-Key Sequence indicates fast-key sequence is applicable only for instrument level ODV.
1. Coordinates are to help locate the item on the Field Communicator Menu Tree for Instrument Level HC, AD, PD, and ODV.
2. Instrument level AD, PD, and ODV only.
3. Instrument level ODV only.
4. Instrument level HC, AD, and PD only.
5. Instrument level HC only.
DVC6200 Digital Valve Controller
Fast-Key
(1)
Coordinates
Sequence
1-2-6-4 4-D
2-1 2-E
1-2-3-6-2
8-F
1-2-3-7-2
1-2-3-6-1
9-F
1-2-3-7-1
3-1 2-F
1-3-2-2 4-E
1-2-5-3-1 6-H
1-2-5-3-2 6-H
1-2-5-2-3 6-G
1-3-1-1 4-E
1-2-4-2-2 8-H
3-6-1 5-G
1-2-3-3-2-2 10-D
1-2-3-3-2-2 10-D
1-2-3-3-2-3 10-D
1-2-5-7 5-F
1-2-1-4-2 5-A
1-2-1-4-1 5-A
1-2-4-2-1 8-H
1-2-5-9-2 6-H
1-2-3-6-4
8-G
1-2-3-7-4
1-2-1-4-3 5-A
Hot Key-2 1-A
1-2-1-2 4-B
1-2-3-1-3-4 12-C
1-2-3-5-1-2 10-F
3-6-5 4-H
1-2-3-5-1-1 10-F
1-2-3-5-1-3 10-F
1-2-5-1-4 6-F
1-2-3-5-2-1 10-F
1-2-2-4 4-C
1-2-5-1-3 6-F
3-8 2-G
3-7-2 4-H
3-7-5 4-H
1-2-4-2-4 8-H
1-2-4-2-3 8-H
1-2-3-6-3
8-F
1-2-3-7-3
1-2-3-1-1 8-C
3-4 2-F
1-2-3-1-2-2 10-C
1-2-3-1-2-1 10-C
Function/Variable
Edit Feedback Connection
(3)
End Point Control Enable
Failure Group Enable
Firmware Revision
Flash ROM Shutdown
Hardware Revision
HART Tag
HART Universal Revision
Input Characterization
Instrument Date and Time
Instrument Level
Instrument Mode
Instrument Serial Number
Instrument Time Invalid Enable
Integral Dead Zone
Integral Limit
Integrator Saturated Hi Enable
Integrator Saturated Lo Enable
(4)
Lag Time
Last Calibration Status
(3)
Lead/Lag
Loop Current Validation Enable
Low Power Write Fail Enable
Manual Calibration
Manufacturer
Maximum Supply Pressure
Message
Miscellaneous Group Enable
Model
Multi-Drop Alert Enable
No Free Time Shutdown
Non-Critical NVM Alert Enable
Number of Power Ups
Offline/Failed Alert Enable
Partial Stroke Test
(3)
Partial Stroke Test Enable
Partial Stroke Test Pressure
(3)
Limit
(3)
Partial Stroke Test Start Point
Fast-Key
(1)
Coordinates
Sequence
1-2-6-6 4-D
1-2-2-2-5-1 6-C
1-2-3-6-5-1
10-G
1-2-3-7-5-1
3-7-6 4-H
1-2-3-1-3-5 12-C
3-7-7 4-I
1-2-5-1-1 6-F
3-7-1 4-H
3-7-9 4-H
1-2-2-3 4-C
1-2-4-1-2 8-G
1-2-5-8 5-F
3-7-8 4-H
Hot Key-1 1-A
1-2-1-1 4-B
1-2-5-1-6 6-F
1-2-4-1-1 8-G
1-2-4-4-4 8-I
1-2-2-1-2-1 9-A
1-2-4-4-3 8-I
1-2-2-1-2-2 9-B
1-2-4-4-1 8-I
1-2-4-4-2 8-I
1-2-2-5-3 6-C
1-2-5-9-1 6-H
1-2-2-5-3 6-C
1-2-3-3-3 9-E
1-2-3-1-3-2 12-B
1-3-1-2 4-E
3-7-3 4-H
1-2-6-1 4-D
1-2-5-6 5-F
1-2-5-1-2 6-F
1-2-3-6-5-3
10-G
1-2-3-7-5-3
3-7-4 4-H
1-2-4-3-2 8-H
1-2-3-1-3-6 12-C
1-2-3-1-3-3 12-B
2-3-4 4-F
3-6-9 5-H
1-2-3-1-3-1 11-B
2-5 2-F
1-2-7-1 3-D
1-2-3-6-1 8-F
1-2-2-2-5-2 8-C
Continued on next page
