Unloading the UPS

CAUTION:
This UPS is very heavy (see
weight in Site Preparation on page 11). At least
two people should be present to unload it from the
pallet.
1. Once the UPS is near the desired operating
location, remove the cardboard cover.
!

UNLOADING

ESC
2. Use a 13mm (1/2in) spanner to remove the
four mounting bolts from the pallet brackets.
Remove mounting brackets from the pallet
and UPS. Keep brackets for future
transportation of UPS, or for additional stability
once in place.
3. Remove the metal ramp from the bottom of the
UPS, rotating it. Fit ramp in pallet slot as
shown above.
