Unloading the UPS

CAUTION: This UPS is very heavy (see weight
on previous page). At least two people should
be present to unload it off of the pallet.
1. Once the UPS is near the desired operating
location, remove the cardboard cover.
2. Use a 13 mm spanner to remove the four
mounting bolts from the pallet brackets.
Remove mounting brackets from the pallet
and UPS. Keep brackets for future
transportation of UPS, or for additional
stability once in place.
Unloading
3. Remove the metal ramp from the bottom of
the UPS, rotating it. Fit ramp in pallet slot as
shown above.
4. Using two people, slowly move the UPS
down the ramp until the UPS is on level
ground.
