Stationary Mounting - Liebert Nfinity User Manual

4. Using two people, slowly move the UPS down
the ramp until the UPS is on level ground.
5. Once the UPS is in its desired location, adjust
the leveling feet to secure its position.

Stationary Mounting

Additional stability can be added by bolting the
mounting brackets (used in shipping) to the floor.
For greater stability, use a higher-grade bolt. Refer
to the dimensions below when drilling holes for
stationary mounting.
Optional Stationary Mounting
711 mm
(28")
13mm
(1/2in)
14
120 mm 120 mm
(4.75") (4.75")
7.94 mm (5/16")
diameter
6 places
