On every Battery, Power or Control Module are two LEDs to help inform the user of the module status.
Refer to the chart below:
Status LED Fault LED
(Green) (Amber)
OFF OFF
OFF ON
FLASHING OFF
FLASHING FLASHING
FLASHING ON
OFF FLASHING
ON OFF
ON ON
ON FLASHING
* If this persists for more than 30 seconds, check to verify the lever is in the down position; otherwise the module is
faulty.
** If both Green and Amber LEDs are flashing for more than 30 seconds, then re-insert module.
Control Module
Power Module
Battery Module

MODULE LED INDICATION

Module not inserted into frame.
System is OFF.
Module is initializing (max 30 seconds*).
Normal Operation
Module is in start-up qualification mode, or module warning. **
Module failed, is off-line and module control is functioning.
Abnormal operation, re-insert module.
If this persists, contact qualified assistance.
Status LED
Fault LED
Status LED
Fault LED
Status LED
Fault LED
Module Status
