5.0 Cable Wiring

Figure 15: Cable Wiring Diagram

Connector Pin #
1
2
3
J1
4
5
6
1
2
J2
3
4
5
1
2
J3
3
4
1
2
3
J4
4
5
6
Input/Output
DI1 Input
DI2 Input
DI3 Input
DI4 Input
- Power 24V
- GND
DO1A Output – N.O. Contact
DO1B Output – N.O. Contact
DO2A Output – N.O. Contact
DO2B Output – N.O. Contact
- No Connect
- Power 24V
AI1 Input
- Power 24V
AI2 Input
AO1 Output
- GND
- Power 24V
- GND
- No Connect
- No Connect
Type
Digital
Digital
Digital
Digital
Digital / Dry Contact
Digital / Dry Contact
Digital / Dry Contact
Digital / Dry Contact
Analog
Analog
Analog
20
OPERATION
Function
Programmable
Programmable
Programmable
Programmable
Programmable
Programmable
Programmable
Programmable
0/20 mA
0/20 mA
4/20 mA
