4.2 Terminal format support

The different input and output ports on HD-OE-2 can support a number of formats. The table
below shows which signal formats are supported on the selected terminals.
Terminal format support:
Terminal Function
OPT1 Optical output
OPT2
OUT1+ Electrical Output –
OUT2+ Reclocked DA
output
OUT1- Electrical Output –
OUT2- Reclocked DA
inverted output
GPI ALARM Open Collector
Alarms
∗
HD-OE-2 has a "Transparent mode". In this mode all reclockers are switched off and no jitter attenuation will be
performed. This mode may be used for non-standard or unsupported bit rates over shorter distances and up to 1
Gbps.
Supported Format
HD-SDI, SDI, DVB-ASI,
SMPTE310M, Transparent∗
HD-SDI, SDI, Transparent*
HD-SDI, SDI, Transparent*
Wired alarms
