Operation & Display

001 Language

001
(LANGUAGE)
Value:
English (ENGLISH)
German (DEUTSCH)
French (FRANCAIS)
Danish (DANSK)
Spanish (ESP ANOL)
Italian (ITALIANO)
Function:
This parameter is used to choose the language to
be shown in the display whenever the LCP control
unit is connected.
Description of choice:
There is a choice of the languages shown. The fac-
tory setting may vary.
002 Local/remote operation
002
(OPERATION SITE)
Value:
Remote operation (REMOTE)
Local operation (LOCAL)
Function:
There is a choice of two different modes of operation
of the frequency converter; Remote operation [0] or
Local operation [1]. See also parameter 013 Local
control if Local operation [1] is selected.
Description of choice:
If Remote operation [0] is selected, the frequency
converter is controlled via:
1. the control terminals or via serial communication.
2. The [START] key. This cannot, however, override
stop commands transmitted via the digital inputs
or via serial communication.
3. The [STOP/RESET] and [JOG] keys, on the con-
dition that these are active.
If Local operation [1], is selected, the frequency con-
verter is controlled via:
1. the [START] key. This cannot, however, override
stop commands via the digital inputs (see param-
eter 013 Local control).
2. The [STOP/RESET] and [JOG] keys, on the con-
dition that these are active.
3. The [FWD/REV] key, on the condition that is has
been selected as active in parameter 016 Local
reversing, and that parameter 013 Local control is
set at Local control and open loop [1] or Local
= factory setting. () = display text [] = value for use in communication via serial communication port
8
®
VLT 2800 Series
control as parameter 100 [3]. Parameter 200 Out-
put frequency range is set at Both directions.
4. parameter 003 Local reference where the refer-
ence can be set using the [+] and [-] keys.
5. an external control command that can be con-
nected to the digital inputs (see parameter 013
[0]
Local control).
[1]
[2]
NB!:
[3]
The [JOG] and [FWD/REV]
[4]
keys are located on the LCP control unit.
[5]

003 Local reference

003
(LOCAL REFERENCE)
Value:
Par.013 Local control must be set to [1] or [2]:
0 - f (par. 202)
MAX
Par. 013 Local control must be set to [3] or [4] and
parameter 203 Reference/feedback range to [0]:
Ref - Ref (par. 204-205)
MIN MAX
Par. 013 Local control must be set to [3] or [4] and
parameter 203 Reference/feedback range to [1]:
- Ref - + Ref
MAX MAX
[0]
[1]
Function:
In this parameter, the local reference can be set
manually . The unit of the local reference depends on
the configuration selected in parameter 100 Configu-
ration.
Description of choice:
In order to protect the local reference, parameter
002 Local/remote operation must be set to Local op-
eration [1]. Local reference cannot be set via serial
communication.
004 Active Setup
004
(ACTIVE SETUP)
Value:
Factory Setup (FACTORY SETUP)
Setup 1 (SETUP 1)
Setup 2 (SETUP 2)
Setup 3 (SETUP 3)
Setup 4 (SETUP 4)
Multi Setup (MULTI SETUP)
Function:
The active parameter Setup is selected here. All pa-
rameters can be programmed in four individual
parameter Setups. Shifts between Setups can be
made in this parameter via a digital input or via se-
rial communication.
MG.28.A5.02 - VLT is a registered Danfoss trade mark
000,000.000
000,000.000
000,000.000
(par. 204-205)
[0]
[1]
[2]
[3]
[4]
[5]
