Power [kW] gives the present power that the motor is
absorbing in kW.
Power [HP] gives the present power that the motor is
absorbing in HP.
Motor voltage[V] gives the voltage supplied to the
motor.
DC link voltage [V] gives the intermediate circuit volt-
age of the frequency converter.
Thermal load motor [%] gives the calculated/esti-
mated load on the motor. 100 % is the cut-out limit.
Thermal load [%] gives the calculated/estimated
thermal load on the frequency converter. 100 % is
the cut-out limit.
Running hours [Hours] gives the number of hours
that the motor has tun since the last reset in param-
eter 619 Reset of running hours counter.
Digital input [Binary code] gives the signal status
from the 5 digital inputs (18, 19, 27, 29 and 33). Ter-
minal 18 corresponds to the bit on the extreme left.
0 ` ' = no signal, 1 ` ' = signal connected.
Analog input 53 [V] gives the voltage value of termi-
nal 53.
Analog input 60 [mA] gives the present value of ter-
minal 60.
Pulse reference [Hz] gives the reference in Hz con-
nected to terminal 33.
External reference [%] gives the sum of external ref-
erences as a percentage (sum of analogue/pulse/
serial communication) in the range from Minimum
reference, Ref to Maximum reference, Ref
MIN
Status word [Hex] gives one or several status condi-
tions in a Hex code. See Serial communication in
the Design Guide for further information.

Heatsink temp.[ C] gives the present heatsink tem-
perature of the frequency converter. The cut-out limit

is 90-100 C, while cutting back in occurs at 70 ± 5

C.
Alarm word [Hex] gives one or several alarms in hex
code. See Serial communication in the Design
Guide for further information.
Control word [Hex] gives the control word for the fre-
quency converter. See Serial communication in the
Design Guide for further information.
= factory setting. () = display text [] = value for use in communication via serial communication port
MG.28.A5.02 - VLT is a registered Danfoss trade mark
®
VLT 2800 Series
Warning word [Hex] gives one or several warnings in
hex code. See Serial communication in the Design
Guide for further information.
Extended status word [Hex] gives one or several sta-
tus modes in Hex code. See Serial communication
in the Design Guide for further information.
Communication option card warning [Hex] gives a
warning word if there is a fault in the communication
bus. Only active if communication options are in-
stalled.
If there are no communication options 0 Hex is dis-
played.
Pulse count gives the number of pulses that the unit
has registered.
010 Small display line 1.1
010
(DISPLAY LINE 1.1)
Value:
See par. 009 Large display readout
Function:
In this parameter, the first of three data values can
be selected that is to be displayed in the LCP control
unit display, line 1, position 1. This is a useful func-
tion, e.g. when setting the PID regulator, as it gives
a view of process reactions to reference changes.
The display readout is activated by pushing the
[DISPLA Y STATUS] key.
Description of choice:
See parameter 009 Large display readout.
.
MAX
011 Small display readout 1.2
011
(DISPLAY LINE 1.2)
Value:
See parameter 009 Large display readout
Function:
See the functional description given under parameter
010 Small display readout.
Reference [%] [1]
Motor current [A][6]
11
