motor. The break points are set in parameters 423-
428 Voltage/frequency.
NB!:
Please note that if a value set in the name-
plate parameters 102-106 is changed, there
will be an automatic change of parameter 108 Stator
resistance and 109 Stator reactance.
102 Motor power P
102
M,N

(MOTOR POWER)

Value:
0.25 - 11 kW
Function:
Here you must set a power value [kW] P
sponding to the motor's rated power. The factory
sets a rated power value [kW] P
the type of unit.
Description of choice:
Set a value that matches the nameplate data on the
motor. Settings between one size below and one
size over the factory setting are possible.
103 Motor voltage U
103
M,N

(MOTOR VOLTAGE)

Value:
For 200 V units: 50 - 999 V
For 400 V units: 50 - 999 V
Function:
This is where to set the rated motor voltage U
1
either star Y or delta
.
Description of choice:
Select a value that corresponds to the nameplate
data on the motor, regardless of the frequency con-
verter's mains voltage.
104 Motor frequency f
104

(MOTOR FREQUENCY)

Value:
24-1000 Hz
Function:
This is where to select the rated motor frequency
f
.
M,N
= factory setting. () = display text [] = value for use in communication via serial communication port
16
Depends on unit
, corre-
M,N
, that depends on
M,N
230 V
400 V
for
M,N
M,N
50 Hz
®
VLT
2800 Series
Description of choice:
Select a value that corresponds to the nameplate
data on the motor.
105 Motor current I
105
M,N

(MOTOR CURRENT)

Value:
Depends on choice of motor
0,01 - I
MAX
Function:
The nominal, rated current of the motor I
part of the frequency converter calculation of fea-
tures such as torque and motor thermal protection.
Description of choice:
Set a value that corresponds to the nameplate data
on the motor. Set the motor current I
account whether the motor is star-connected Y or
1
delta-connected
.
106 Rated motor speed
106
(MOTOR NOM. SPEED)
Value:
100 - f
x 60 (max. 60000 rpm)
M,N
Depends on parameter 102 Motor power, P
Function:
This is where to set the value that corresponds to
the rated motor speed n
M,N
the nameplate data.
Description of choice:
Select a value that corresponds to the nameplate
data on the motor.
NB!:
The max. value equals f
set in parameter 104 Motor frequency, f
107 Automatic motor tuning, AMT
107
(AUTO MOTOR TUN.)
Value:
Optimisation off (AMT OFF)
Optimisation on (AMT START)
NB!:
AMT is not possible on VLT 2880–82
Function:
Automatic motor tuning is an algorithm that mea-
sures stator resistance R
S
MG.28.A5.02 - VLT is a registered Danfoss trade mark
forms
M,N
taking into
M,N
M,N
that can be seen from
x 60. f
to be
M,N
M,N
.
M,N
[0]
[2]
without the motor axle
