Description of choice:
Factory Setup [0] contains the factory-set parameter
values. Setup 1-4 [1]-[4] are four individual Setups
which can be selected as required. Multi Setup [5] is
used where remote-controlled shifts between the
four Setups via a digital input or via serial communi-
cation is required.
005 Programming Setup 005
(EDIT SETUP)
Value:
Factory Setup (FACTORY SETUP)
Setup 1 (SETUP 1)
Setup 2 (SETUP 2)
Setup 3 (SETUP 3)
Setup 4 (SETUP 4)
Active Setup (ACTIVE SETUP)
Function:
You can select which Setup you want to programme
during operation (applies both via the control panel
and the serial communication port). It is, for exam-
ple, possible to programme Setup 2 [2], while the
active Setup is set to Setup 1 [1] in parameter 004
Active Setup.
Description of choice:
Factory Setup [0] contains the factory-set data and
can be used as a source of data if the other Setups
are to be reset to a known status. Setup 1-4 [1]-[4]
are individual Setups that can be programmed freely
during operation. If Active Setup [5] is selected, the
programming Setup will be equal to parameter 004
Active Setup.
NB!:
If data is modified or copied to the active
Setup, the modifications have an immediate
effect on the unit's operation.
006 Setup copying
006
(SETUP COPY)
Value:
No copying (NO COPY)
Copy to Setup 1 from #
(COPY TO SETUP 1 )
Copy to Setup 2 from #
(COPY TO SETUP 2)
Copy to Setup 3 from #
(COPY TO SETUP 3)
Copy to Setup 4 from #
(COPY TO SETUP 4)
Copy to all Setups from # (COPY TO ALL)
= factory setting. () = display text [] = value for use in communication via serial communication port
MG.28.A5.02 - VLT is a registered Danfoss trade mark
®
VLT 2800 Series
Function:
You can copy from the selected active Setup in pa-
rameter 005 Programming setup to the selected
Setup or Setups in this parameter.
NB!:
Copying is only possible in Stop (motor
stopped in connection with a stop command).
Description of choice:
Copying begins when the required copying function
has been selected and the [OK]/[CHANGE DATA]
key has been pushed. The display indicates when
copying is in progress.
[0]
[1]
[2]
[3]
007 LCP copy
007
[4]
(LCP COPY)
[5]
Value:
No copying (NO COPY)
Upload all parameters (UPL. ALL PAR.)
Download all parameters (DWNL. ALL PAR.)
Download size-independent parameters
(DWNL.OUTPIND.P AR.)
Function:
Parameter 007 LCP copy is used if you want to use
the LCP2 control panel's integral copy function. The
function is used ifyou want to copy all parameter se-
tups from one frequency converter to another by
moving the LCP2 control panel.
Description of choice:
Select Upload all parameters [1] if you want all pa-
rameter values to be transferred to the control panel.
Select Download all parameters [2] if all parameter
values transferred are to be copied to the frequency
converter to which the control panel is attached. Se-
lect Download size-independent par. [3] if you only
want to downloade the size-independent parameters.
This is used when downloading to a frequency con-
verter with a different rated power size than that from
which the parameter setup originates.
[0]
[1]
[2]
[3]
[4]
[5]
[0]
[1]
[2]
[3]
