mains voltage is cut back in. Parameter 003 Local
reference is to be zeroed.
NB!:
In remote operation (parameter 002 Local/
remote operation) the start/stop state at the
time of mains connection will depend on the external
control signals. If Pulse start [8] is selected in pa-
rameter 302 Digital input, the motor will remain
stopped after mains connection.
020 Lock for Hand mode
020
(LOCK HAND MODE)
Value:
Not active (DISABLE)
Active (ENABLE)
Function:
In this parameter you can select whether it should
be possible or not to switch between Auto- and Hand
mode. In Auto mode the frequency converter is con-
trolled by external signals whereas the frequency
converter in Hand mode is controlled via a local ref-
erence directly from the control unit.
Description of choice:
If Not active [0] is selected in this parameter, the
Hand mode function will be inactive. This blocking
can be activated as desired. If Active [1] is selected
you can switch between Auto- and Hand mode. For
further information, see the Control Unit section.
024 Userdefined Quick Menu
024
(USER QUICKMENU)
Value:
Not active (DISABLE)
Active (ENABLE)
Function:
In this parameter you can opt out of the standard
setup of the Quick menu key on the control panel
and the LCP2 control panel.
Using this function, in parameter 025 Quick Menu
setup the user can select up to 20 parameters for
the Quick Menu key.
Description of choice:
If not active [0] is selected, the standard setup of the
Quick Menu key is active.
= factory setting. () = display text [] = value for use in communication via serial communication port
14
®
VLT
2800 Series
If Active [1] is selected, the user-defined Quick Menu
is active.
025 Quick Menu setup
025
(QUICK MENU SETUP)
Value:
[Index 1 - 20] Value: 0 - 999
Function:
In this parameter you define which parameters are
required in the Quick Menu when parameter 024
User-defined Quick Menu is set to Active [1]. ´
Up to 20 parameters can be selected for the user-
[0]
defined Quick Menu.
[1]
NB!:
Please note that this parameter can only be
set using an LCP2 control panel. See Order
form.
Description of choice:
The Quick Menu is set up as follows:
1. Select parameter 025 Quick Menu setup and
press [CHANGE DATA].
2. Index 1 indicates the first parameter in Quick
Menu. You can scroll between the index numbers
using the [+ / -] keys. Select Index 1.
3. Using [< >] you can scroll between the three fig-
ures. Press the [<] key once ad the last number
in the parameter number can be selected using
the [+ / -] keys.
Set Index 1 to 100 for parameter 100 Configura-
tion.
4. Press [OK] when Index 1 has been set to 100.
5. Repeat steps 2 - 4 until all parameters required
have been set to the Quick Menu key.
[0]
6. Press [OK] to complete the Quick Menu setup.
[1]
If parameter 100 Configuration is selected at Index
1, Quick Menu will start with this parameter every
time Quick Menu is activated.
Please note that parameter 024 User-defined Quick
Menu and parameter 025 Quick Menu setup are re-
set to the factory setting during initialisation.
MG.28.A5.02 - VLT is a registered Danfoss trade mark
